Old 12-29-2010, 05:34 PM   #31
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Ditched the tiny bolt on style bracket for these from ballistic fab they push the axle back 3 inches and down 2 thus making the overall lift 7.5". That's actually a little too much but gives me the ability to use shorter springs that will give the link bars a better angle

4x4builder1 is offline   Quote Quick Reply
Old 12-29-2010, 05:41 PM   #32
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
35 out 14 bolt in I'm not sure what to use in the 03 since this was supposed to be for that

4x4builder1 is offline   Quote Quick Reply
Old 01-01-2011, 04:19 PM   #33
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Got the motor out today

4x4builder1 is offline   Quote Quick Reply
Old 01-01-2011, 04:23 PM   #34
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
This is the previous owners rear setup I think its cherokee springs not what I what but it will help with $$ to link the front first then worry about the rear later
4x4builder1 is offline   Quote Quick Reply
Old 01-01-2011, 04:27 PM   #35
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
sstill wondering why he cut the frame then tacked it back on I will take it back off and weld it back up aligned correctly and fish plate it for strength
4x4builder1 is offline   Quote Quick Reply
Old 01-01-2011, 06:08 PM   #36
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Getting the electronics together to install ignition fuel injection computer harnesses and switch panel leaving provisions for kc's as headlights a winch backup lights and a 3000 watt inverter for camping or tools. The 200 amp alternator will handle just about anything I need.
4x4builder1 is offline   Quote Quick Reply
Old 01-01-2011, 06:29 PM   #37
I HAVE A BELLYBUTTON!

WF Supporting Member

cavediverjc's Avatar

Join Date: Mar 2007
Location: On the grassy knoll...
Posts: 6,983
I'm looking forward to watching these builds progress. Looks great, man!
__________________
Americans sleep safely in their beds because rough men stand ready in the night to visit violence on those who would do them harm...

Happiness is a Barrett M82A1 .50 caliber and a target at least a click out........

I come in peace. I didn't bring artillery. But I'm pleading with you with tears in my eyes, if you f**k with me, I'll kill you all.....
cavediverjc is offline   Quote Quick Reply
Old 01-10-2011, 07:24 PM   #38
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Finally have the rest of my rebuild parts for the th400 tci ultimate master rebuild 34 sprag element billet input shaft and billet aluminum forward drum. Also got a fluidyne trans cooler since I'm using a 3500 stall. A friend uses this same cooler in his top sportsman car so it should be plenty for the jeep.


4x4builder1 is offline   Quote Quick Reply
Old 01-14-2011, 02:03 AM   #39
Member

Join Date: Aug 2010
Location: somewhere....
Posts: 11,188
Looks good dude. keep us updated
redjeeper is offline   Quote Quick Reply
Old 02-12-2011, 10:18 PM   #40
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
picked up the dana 60 out of a 86 F350 tow truck been tearing into it the past few days have to convert it to single wheel hubs and fully rebuild

so far have new 4.10 gear set installed with new bearings and seals. Pulled spindles and knuckles to blast and powdercoat ordering rcv performance axle shafts soon

pulled the 97 body off to swap the 03 on to this chassis

moving along nice did the mounts today too dark for more picks but the original 6 body mounts on the outer frame rails had to come off but the tj frame mounts were almost perfect just had to cut them off the tj frame and bolt up to the tub then weld up

also picked up a nice tuffy center console for $100 that way i can lock the $2000 efi computer in it cant have anybody running away with that
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 07:00 PM   #41
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Ordered heat extractor hood panel, painted and installed tonight too dark for pic.
[IMG][/IMG]
Got the front rear in just waiting for the ballistic fab high steer kit so I can install the knuckles and finish it up
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 07:10 PM   #42
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Built an enclosure for the new RCI cell welded flush to the floor behind the rear seat
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 07:11 PM   #43
Jeeper

EdJonesJeeper's Avatar

Join Date: Jan 2010
Location: Western NC
Posts: 1,005
Wow nice builds man! More Pics please
__________________
99' TJ Sahara d44 on 35's
EdJonesJeeper is offline   Quote Quick Reply
Old 03-03-2011, 07:23 PM   #44
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286

4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 07:48 PM   #45
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 07:54 PM   #46
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Dash with airbag removed
[IMG][/IMG]
Airbag removed from cradle to install ignition box
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 08:12 PM   #47
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Ditched the msd off-road for the new hvc setup times 2 that way I can switch between systems on the fly. Msd techs told me there not for the street since they make so much more power causing more heat in the boxes. I'm coming up with a way to mount the second box near the other one and a fan setup to prevent overheating.
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 08:16 PM   #48
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 08:20 PM   #49
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
After seeing how much room there is above the tire I'm going to order a set of full armor fenders with 6" flares to fix the mess of a comp cut the previous owner did.
4x4builder1 is offline   Quote Quick Reply
Old 03-03-2011, 08:29 PM   #50
Jeeper

07XMan2Door's Avatar

Join Date: Nov 2010
Location: colorado
Posts: 1,680
Dude, you're an animal!! I cant imagine the pride you will have driving those things once they are up & running. Your sticktoitevness blows my mind. Great job thus far, keep up the great work & thanks for posting!!
07XMan2Door is offline   Quote Quick Reply
Old 03-03-2011, 08:37 PM   #51
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Quote:
Originally Posted by 07XMan2Door View Post
Dude, you're an animal!! I cant imagine the pride you will have driving those things once they are up & running. Your sticktoitevness blows my mind. Great job thus far, keep up the great work & thanks for posting!!
Thanks man can't wait to finish em up the 03 will be on the road in a week
4x4builder1 is offline   Quote Quick Reply
Old 03-04-2011, 06:13 PM   #52
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
With a torch and some leverage I bent a set of hooked super comps about an inch to fit in-between the frame rails the headers were intended for a Chevy pickup I had them on this motor in my 99 tahoe.
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-04-2011, 06:17 PM   #53
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
need to figure out what to do with the steering might move the joint up for more clearance
4x4builder1 is offline   Quote Quick Reply
Old 03-09-2011, 09:29 AM   #54
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Got rid of the airbag holder made a bracket to weld in much cleaner and more open air to cool the msd
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-09-2011, 09:35 AM   #55
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-09-2011, 09:37 AM   #56
MTH
Fun Killing Ninja

MTH's Avatar

Join Date: Oct 2010
Location: North Carolina
Posts: 8,542
WOW. Can't wait to see the results. Awesome.
MTH is offline   Quote Quick Reply
Old 03-09-2011, 09:57 AM   #57
Jeeper

07XMan2Door's Avatar

Join Date: Nov 2010
Location: colorado
Posts: 1,680
I can't believe you have accomplished all of this outside & in the winter time!! Balls of steel my friend, balls of steel!!!
07XMan2Door is offline   Quote Quick Reply
Old 03-10-2011, 09:02 AM   #58
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Yup no room in the garage by the way this thing isn't even at my house its at a friends my town frowns upon these projects of mine.
4x4builder1 is offline   Quote Quick Reply
Old 03-14-2011, 09:17 PM   #59
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Computers in fired up and soft tuned for the new throttle body since the old one didn't have an idle air control sensor now it idles much better and has a more streetable throttle response
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-14-2011, 10:02 PM   #60
Jeeper

4wd4GOD's Avatar

Join Date: Mar 2011
Location: Vacaville, CA
Posts: 43
Awesome builds, looking forward to seeing the finished product.

__________________
If you canít get there in a Jeep
-----oooo
-/| ,[Jeep],
|---L ĖO|||||O-
()_)-()_)-o-)_)
Itís probably not worth going
