Old 03-16-2011, 08:01 PM   #61
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Here's the console before the shifter install
[IMG][/IMG]
[IMG][/IMG]
Still have some more work to do but its coming out nice
[IMG][/IMG]

4x4builder1 is offline   Quote Quick Reply
Old 03-16-2011, 08:11 PM   #62
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
got the first coat of POR 15 down a few days ago second coat going on tomorrow and I'll cut in what got missed the first time around
[IMG][/IMG]

4x4builder1 is offline   Quote Quick Reply
Old 03-17-2011, 03:48 PM   #63
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
shifter mount
[IMG][/IMG]
[IMG][/IMG]
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-18-2011, 09:13 PM   #64
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-19-2011, 01:03 PM   #65
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
[IMG][/IMG]
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-21-2011, 08:26 PM   #66
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
here's the basic idea for the oil cooler right under the hood with 2 fans below to pull air from the vents
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-21-2011, 08:57 PM   #67
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Setting up the high steer using the original tie rod from the f350 that the Dana 60 came from
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-21-2011, 09:26 PM   #68
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Since I did custom motor mounts and located the motor 3" further foward then a typical novak or advance adapters setup to get a better driveshaft angle there's not much room between the electric water pump and fan. They don't touch and shouldnt under throttle either
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-21-2011, 11:20 PM   #69
Jeeper

07XMan2Door's Avatar

Join Date: Nov 2010
Location: colorado
Posts: 1,691
Truly Amazing build Brother!! You got mad skills.
07XMan2Door is offline   Quote Quick Reply
Old 03-22-2011, 10:41 PM   #70
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Even though it would have been bolt on I decided against the yj steering box. I torched a 2004 box mount to fit on my frame and use the 04 box drilled out to 3/4 for the heim joint.
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-22-2011, 10:57 PM   #71
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
the mount is a Hell of alot stronger then stock now fully welded all the way around and fish plated.
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-25-2011, 06:42 PM   #72
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Shift light set at 6k rpm, fast xfi rpm limit is set at 7k
[IMG][/IMG]
Dual coil set up
[IMG][/IMG]
Panel installed
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 03-25-2011, 06:51 PM   #73
M_
Jeeper

WF Supporting Member

Join Date: Mar 2011
Posts: 2,009
Images: 1
Where in nj are you?
M_ is offline   Quote Quick Reply
Old 03-25-2011, 08:47 PM   #74
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
I live in Marlton but the jeeps at a friends house in Berlin
4x4builder1 is offline   Quote Quick Reply
Old 03-25-2011, 09:08 PM   #75
Jeeper

Geno's Avatar

Join Date: Jan 2011
Location: Central California
Posts: 492
You are trully an ANIMAL! I love this build. And like stated, in the winter, outside! I am not worthy!! Keep up the great work!
Geno is offline   Quote Quick Reply
Old 03-25-2011, 09:18 PM   #76
M_
Jeeper

WF Supporting Member

Join Date: Mar 2011
Posts: 2,009
Images: 1
Sweet I'm in clementon like 5 minutes away from Berlin... I bounce at pjs In cherry hill hope to see you guys out there when they're all finished up they sound pretty sweet! If you see me say hey
Attached Thumbnails
Click image for larger version

Name:	image-1142491440.jpg
Views:	187
Size:	75.0 KB
ID:	42734
M_ is offline   Quote Quick Reply
Old 03-25-2011, 10:21 PM   #77
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Hey thanks guys about 2 weeks till she's done I've even been having stuff overnighted instead of ground shipping so I can just get it done! Wife is not happy about that, m mcquade wharton 2 weeks first test run ill post it when were goin gonna be 5 jeeps and a Chevy so far but the more the better. Hoping she holds together but I'm going to try and break all the weak links right out of the gate, bringing the welder tools and spare parts just incase.
4x4builder1 is offline   Quote Quick Reply
Old 03-25-2011, 10:22 PM   #78
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
nice yj man can't wait to see it
4x4builder1 is offline   Quote Quick Reply
Old 03-26-2011, 12:39 AM   #79
M_
Jeeper

WF Supporting Member

Join Date: Mar 2011
Posts: 2,009
Images: 1
NICE!!! definitely keep me posted
M_ is offline   Quote Quick Reply
Old 03-26-2011, 12:42 AM   #80
M_
Jeeper

WF Supporting Member

Join Date: Mar 2011
Posts: 2,009
Images: 1
Quote:
Originally Posted by 4x4builder1
nice yj man can't wait to see it
Thanks, I hope I can keep up!!!
M_ is offline   Quote Quick Reply
Old 03-27-2011, 10:55 PM   #81
Jeeper

Blacksurt's Avatar

Join Date: Feb 2011
Location: New Mexico
Posts: 161
Images: 1
Nice! Keep the pics coming!
Blacksurt is offline   Quote Quick Reply
Old 03-30-2011, 10:00 PM   #82
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
First start up and tune with the new ignition went bad the box is toast here's the video with the old msd off-road. Only casualty was a header gasket which is odd since I used stage 8 locking header bolts taken on my evo cracked camera lens little fuzzy. Check out the flames! YouTube - March 30, 2011 9:18 PM
4x4builder1 is offline   Quote Quick Reply
Old 03-30-2011, 10:10 PM   #83
M_
Jeeper

WF Supporting Member

Join Date: Mar 2011
Posts: 2,009
Images: 1
:::doh!!!::: hope you still get everything running by next weekend!
M_ is offline   Quote Quick Reply
Old 03-30-2011, 10:48 PM   #84
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
As long as I get my trans back still waiting on that since January!
4x4builder1 is offline   Quote Quick Reply
Old 04-08-2011, 10:56 PM   #85
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Still no trans going over there tomorrow to make sure it gets done. added a second filter to the fuel system after seeing this, only used this filter for 3 months in a brand new fuel cell!
[IMG][/IMG]
steel mesh 100 Micron before pump composite 10 Micron after
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 04-08-2011, 11:13 PM   #86
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
1 of the gauge pods the pillar pod is on back order from quadratec. red-oil press warning light amber- water temp warning
[IMG][/IMG]
[IMG][/IMG]
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 04-08-2011, 11:19 PM   #87
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
Oil cooler mounted installing lines tomorrow
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 04-09-2011, 11:25 PM   #88
Jeeper

4x4builder1's Avatar

Join Date: Dec 2010
Location: Atco
Posts: 286
oil cooler and billet filter lines
[IMG][/IMG]
New valve spring oilers installed
[IMG][/IMG]
4x4builder1 is offline   Quote Quick Reply
Old 04-09-2011, 11:51 PM   #89
Jeeper

07XMan2Door's Avatar

Join Date: Nov 2010
Location: colorado
Posts: 1,691
You're an animal!! Looking good!!
07XMan2Door is offline   Quote Quick Reply
Old 04-11-2011, 12:09 AM   #90
Jeeper

MikeMTJ's Avatar

Join Date: Nov 2009
Location: If only I knew....
Posts: 2,113
Send a message via AIM to MikeMTJ
I'm drooling.

I ruined another keyboard from drool.

MikeMTJ is offline   Quote Quick Reply
