Old 08-14-2013, 07:04 PM   #91
Rock-Rubber

WF Supporting Member

GoldenSahara00's Avatar

Join Date: Aug 2010
Location: SCPA
Posts: 16,729
I absolutely agree, no question about it. 12" will be stretching it anyways and like you said it's plenty to work with.

Rob that looks great and pretty much what I had in mind when thinking over this. I agree about the shock comments. very nice clean functional setup.

__________________
Ryan - A good eye, a light foot, and a smart rig.
Bolt-ons are boring
AMERICAN JEEPER
My Build - http://www.wranglerforum.com/f118/pr...a00-74622.html
Rausch Creek Trip: 2014 Trip Coming Soon
GoldenSahara00 is online now   Quote Quick Reply
Old 08-14-2013, 07:07 PM   #92
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
this might have some stuff on it that might give some visual. IDK...

This was about 2 yrs ago when it first started running.

Saw the front uppers

Good lookin jeep! We may need to make the trip out to you at some point too

__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-14-2013, 09:13 PM   #93
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53

This might show it better
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-16-2013, 11:49 AM   #94
Jeeper

WOKNROX's Avatar

Join Date: Oct 2012
Location: SoCal Hi Dez
Posts: 3,609
The jeep is really coming along nicely Geoff.... Big Haus Rob is a cool and very knowledgeable guy with great experience too.
Just wanted to say Thanx Robert for everything. I received the shifters the next day got them installed and they work awesome!
Thanks again
SteveO
__________________


WOKNROX!
Let's go wheelin!™
WOKNROX is offline   Quote Quick Reply
Old 08-17-2013, 11:02 PM   #95
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by WOKNROX View Post
The jeep is really coming along nicely Geoff.... Big Haus Rob is a cool and very knowledgeable guy with great experience too.
Just wanted to say Thanx Robert for everything. I received the shifters the next day got them installed and they work awesome!
Thanks again
SteveO
Thanks steve! We got some more work done today, so I will probably post some more pics in the next day or two.
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-18-2013, 12:29 AM   #96
Jeeper

WOKNROX's Avatar

Join Date: Oct 2012
Location: SoCal Hi Dez
Posts: 3,609
Right on Bud....can't wait to see it...
I put the new automatic transmission through its motions today on Sledge Hammer!
I'm diggin it...really likin the shifters too!
__________________


WOKNROX!
Let's go wheelin!™
WOKNROX is offline   Quote Quick Reply
Old 08-18-2013, 01:15 AM   #97
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by WOKNROX View Post
Right on Bud....can't wait to see it...
I put the new automatic transmission through its motions today on Sledge Hammer!
I'm diggin it...really likin the shifters too!
Nice! Cant wait to meet up again to check it out!
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-18-2013, 07:46 PM   #98
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
This weekend we started mocking the front axle up. We are pretty close to having it the way we want. Just need to modify a couple of brackets due to contact issues when cycling the axle. Overall, fitment wasn't too bad. We did run into quite a bit of modifying on the driver side. Since this axle came out of a leaf sprung ford, it had a cast perch near the diff where the leaf spring mounts. Thankfully everything lined up to where we "modified" (i.e. cut up the coil spring perch) to make the coil spring perch part of this cast perch. Doesn't make much sense I know...so I will try to get a picture of what I am talking about later. In the mean time...here is what we have so far.
Tacking the brackets on out in the driveway.


Playing around with it while it's under the jeep


This is the best picture I have of the driver side spring perch. I circled what I was talking about in red. We basically cut the mount we had to fit around the perch that was there...essentially making the factory perch park of our coil perch. The heights were identical so it really couldnt have worked any better.
Click image for larger version

Name:	D44.jpg
Views:	41
Size:	225.2 KB
ID:	287373
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-18-2013, 10:33 PM   #99
Jeeper

WOKNROX's Avatar

Join Date: Oct 2012
Location: SoCal Hi Dez
Posts: 3,609
Looks good guys...always nice when things workout like that...also looks like all you need to do is drill and tap the passenger side knuckle and you've got some high steer knuckles too...
Did you get a chance to checkout.. Redneck Ram yet..?

Man I love this part of jeep builds....to there's nothing more fun then pulling junkyard parts and adapting them to your rig....nice job guys.
__________________


WOKNROX!
Let's go wheelin!™
WOKNROX is offline   Quote Quick Reply
Old 08-18-2013, 10:40 PM   #100
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by WOKNROX View Post
Looks good guys...always nice when things workout like that...also looks like all you need to do is drill and tap the passenger side knuckle and you've got some high steer knuckles too...
Did you get a chance to checkout.. Redneck Ram yet..?

Man I love this part of jeep builds....to there's nothing more fun then pulling junkyard parts and adapting them to your rig....nice job guys.
Ya, the flat top knuckles make that easy! I have looked at the redneck ram. I also have a write up to drill and tap a saginaw box to convert it to hydro assist.

Making the junkyard stuff work is pretty cool. Nothing like a true Poor Boy build!
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-18-2013, 10:48 PM   #101
Jeeper

WOKNROX's Avatar

Join Date: Oct 2012
Location: SoCal Hi Dez
Posts: 3,609
Right on...I'll have to check it out....on another note if you grab the master cylinder from an Astro van it gives you hydro boost power breaks instead of vacuum.... in addition to giving you stronger/ better breaks it also takes up less room too...
__________________


WOKNROX!
Let's go wheelin!™
WOKNROX is offline   Quote Quick Reply
Old 08-18-2013, 11:13 PM   #102
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by WOKNROX View Post
Right on...I'll have to check it out....on another note if you grab the master cylinder from an Astro van it gives you hydro boost power breaks instead of vacuum.... in addition to giving you stronger/ better breaks it also takes up less room too...
Noted! Great tip...ill make sure to look into that.
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-19-2013, 10:12 AM   #103
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53
what both myself and Cal run is the WJ booster and master. Its a direct bold on with a few brake fitting adapters (mm to sae), and is all either of us need on 35's.

Ask your brake guy :-)
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-19-2013, 10:38 AM   #104
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
what both myself and Cal run is the WJ booster and master. Its a direct bold on with a few brake fitting adapters (mm to sae), and is all either of us need on 35's.

Ask your brake guy :-)
I actually read about this too on Cal's build thread over on NAXJA...so definitely a viable option as well.
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-19-2013, 10:47 AM   #105
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53
I would suggest removing/leaving off, one upper arm. A radius arm style is notorious for binding when articulating and even ripping mounts off. If you remove one upper it greatly reduces the amount of bind.

This is of course if your upper mount on the side you leave on, is stout.
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-19-2013, 10:49 AM   #106
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
I would suggest removing/leaving off, one upper arm. A radius arm style is notorious for binding when articulating and even ripping mounts off. If you remove one upper it greatly reduces the amount of bind.

This is of course if your upper mount on the side you leave on, is stout.
Does it matter which?
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-19-2013, 10:54 AM   #107
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53
In your case not really. If you had a cast in place upper mount, then most would leave that one. Since in theory its thought to be the stronger of both upper mounts.

In your case you could leave all that bridge off, and just really do up a nice Strong pass upper and that way you have less 'stuff' on the driverside, where you have exh, driveshaft and yoke and your casting stuff from the D44.
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-19-2013, 11:04 AM   #108
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
In your case not really. If you had a cast in place upper mount, then most would leave that one. Since in theory its thought to be the stronger of both upper mounts.

In your case you could leave all that bridge off, and just really do up a nice Strong pass upper and that way you have less 'stuff' on the driverside, where you have exh, driveshaft and yoke and your casting stuff from the D44.
That makes sense. We were running into some clearance issues on the driver side, so that would totally makes sense. Would there be a benefit to putting a joint on the axle end of the lower link that isn't running an upper...or would this create too much movement?
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-19-2013, 11:07 AM   #109
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53
Is it just a rubber incased bushing now? If so then that will limit a slight bit. You cant really get "movement" unless it binds and the binding creates forces that force things around.

I would Highly suggest you really make sure your track bar is attached Very well and that you brace up the upper mount very well.
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-19-2013, 11:21 AM   #110
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
Is it just a rubber incased bushing now? If so then that will limit a slight bit. You cant really get "movement" unless it binds and the binding creates forces that force things around.

I would Highly suggest you really make sure your track bar is attached Very well and that you brace up the upper mount very well.
Good stuff Rob...thank you!
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 11:34 AM   #111
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Part of our latest order came in last night...the rest of it should be in this afternoon.

Yukon Superjoints!
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 12:03 PM   #112
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Question for you Rob, (I haven't looked at the official install instructions yet, since we arent ready to install), but what is the best procedure for installing the Super Joints? I have read a little bit about galling with the Super Joints due poor installation or lack of grease. Is there anything special you recommend for installation and/or maintenance of these joints? I know you are a Yukon guy, so I'm sure you have ran into this stuff before.
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 12:26 PM   #113
Jeeper

RWKHaus's Avatar

Join Date: Nov 2009
Location: Yorba Linda
Posts: 53
Just grease them after every trail or event.

Install is just like any other ujoint.
__________________
Differential Specialist
RWKHaus is offline   Quote Quick Reply
Old 08-21-2013, 12:30 PM   #114
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by RWKHausSupply View Post
Just grease them after every trail or event.

Install is just like any other ujoint.
Awesome thanks. Same as what I have read everywhere else
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 12:42 PM   #115
Rock-Rubber

WF Supporting Member

GoldenSahara00's Avatar

Join Date: Aug 2010
Location: SCPA
Posts: 16,729
Saweet
__________________
Ryan - A good eye, a light foot, and a smart rig.
Bolt-ons are boring
AMERICAN JEEPER
My Build - http://www.wranglerforum.com/f118/pr...a00-74622.html
Rausch Creek Trip: 2014 Trip Coming Soon
GoldenSahara00 is online now   Quote Quick Reply
Old 08-21-2013, 12:46 PM   #116
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by GoldenSahara00 View Post
Saweet
Definitely. I know I have said this a few times...but this weekend we should REALLY have the axles under the jeep . We have one little thing to tweak on the front axle...then burn it all in. Then just a couple perches on the rear. They probably wont be trussed this weekend...but the jeep should be able to sit on it's own weight. Then it's time for driveshaft measurements that will be sent off to Mr. Tom Woods
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 02:55 PM   #117
Rock-Rubber

WF Supporting Member

GoldenSahara00's Avatar

Join Date: Aug 2010
Location: SCPA
Posts: 16,729
How do those compare in price with CTMs? I've looked at them all before briefly but it seems like a load of cash to spend.

I know how it is swapping an axle, I'm a perfectionist and like everything just right. Hopefully see that thing rolling soon
__________________
Ryan - A good eye, a light foot, and a smart rig.
Bolt-ons are boring
AMERICAN JEEPER
My Build - http://www.wranglerforum.com/f118/pr...a00-74622.html
Rausch Creek Trip: 2014 Trip Coming Soon
GoldenSahara00 is online now   Quote Quick Reply
Old 08-21-2013, 03:22 PM   #118
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Quote:
Originally Posted by GoldenSahara00 View Post
How do those compare in price with CTMs? I've looked at them all before briefly but it seems like a load of cash to spend.

I know how it is swapping an axle, I'm a perfectionist and like everything just right. Hopefully see that thing rolling soon
Price wise, at retail, CTMs run around 240 a piece...so 480 a pair. The yukons are about 360 pair.
__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Old 08-21-2013, 04:15 PM   #119
Rock-Rubber

WF Supporting Member

GoldenSahara00's Avatar

Join Date: Aug 2010
Location: SCPA
Posts: 16,729
Still a good chunk either way. Theres still the longfield too. 300M DANA 44 & DANA 60 U JOINTS **NEW** - Longfield Super Axles

I think ox quit making theres though right?

Still a heck of a chunk of change. That's why this sport takes money though right.
__________________
Ryan - A good eye, a light foot, and a smart rig.
Bolt-ons are boring
AMERICAN JEEPER
My Build - http://www.wranglerforum.com/f118/pr...a00-74622.html
Rausch Creek Trip: 2014 Trip Coming Soon
GoldenSahara00 is online now   Quote Quick Reply
Old 08-21-2013, 04:22 PM   #120
The Rogue Moderator

::WF Moderator::

Cons_Table's Avatar

Join Date: Aug 2009
Location: Ridgecrest, CA
Posts: 7,572
Ya I don't believe OX makes their joint anymore.

But ya, it's definitely not cheap! That's where sponsorships and promoting play a role

__________________
Poor Boy Racing The definition of the EVERYMAN Challenge!

Everyman Challenge XJ Build
Cons_Table is offline   Quote Quick Reply
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the Jeep Wrangler Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid email address for yourself.
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off




Download our Mobile App

» Network Links
»Jeep Parts
» Featured Product

All times are GMT -5. The time now is 01:05 PM.



Jeep®, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
