Old 02-20-2011, 08:47 PM   #1
Jeeper

Teco210wrangler's Avatar

Join Date: Sep 2010
Posts: 43
lockers

What are the lockers for?? What would I need them for??? 2010 wrangler 4door sport..

Teco210wrangler is offline   Quote Quick Reply
Old 02-20-2011, 08:51 PM   #2
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792

Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 08:54 PM   #3
Jeeper

ncossey's Avatar

Join Date: Aug 2010
Location: Fort Smith, AR
Posts: 1,180
Quote:
Originally Posted by Teco210wrangler
What are the lockers for?? What would I need them for??? 2010 wrangler 4door sport..
Not to be rude, but if you dont know what they are, you will probably never miss them or need them.
__________________
There are very few vehicles that can be defined as "made for offroad". Unfortunately, the Wrangler can definitely be defined as "made for offroad" by its inability to handle well on road
ncossey is offline   Quote Quick Reply
Old 02-20-2011, 09:00 PM   #4
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792
To know what a locker does you first need to know what the differential does. This video will get you started. Feel free to ask any questions you have. There are plenty of folks here who'll be happy to teach you.

Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 09:02 PM   #5
The Bad Guy

WF Supporting Member

daggo66's Avatar

Join Date: May 2009
Location: NJ exile living in Baltimore
Posts: 22,119
Quote:
Originally Posted by ncossey View Post
Not to be rude, but if you dont know what they are, you will probably never miss them or need them.
Now if I said that all heck would break loose.
__________________
Tom

"I've got two things in this world, my balls and my word and I don't break them for no one."
daggo66 is offline   Quote Quick Reply
Old 02-20-2011, 09:03 PM   #6
Jeeper

joe002's Avatar

Join Date: Nov 2010
Location: Phoenix, AZ
Posts: 1,186
They helped getting up this hill - especially where you see all of the tire marks (with lockers you just crawl up the first hill, without thereís some tire spin required):
joe002 is offline   Quote Quick Reply
Old 02-20-2011, 09:04 PM   #7
In a trailer in the woods

WF Supporting Member

Barrie's Avatar

Join Date: Feb 2008
Location: Greater downtown Brownsville,Kentucky
Posts: 40,095
Send a message via AIM to Barrie Send a message via Yahoo to Barrie
Quote:
Originally Posted by daggo66 View Post
Now if I said that all heck would break loose.


Some just learn quicker than others Tom.
__________________
2006 Unlimited Soft Top


Skillfully disguised as a responsible adult


Barrie is offline   Quote Quick Reply
Old 02-20-2011, 09:12 PM   #8
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792
Here's another video that will help you understand.

Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 09:13 PM   #9
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792
Quote:
Originally Posted by joe002 View Post
They helped getting up this hill - especially where you see all of the tire marks (with lockers you just crawl up the first hill, without thereís some tire spin required):
That looks like my kinda hill!
Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 09:15 PM   #10
In a trailer in the woods

WF Supporting Member

Barrie's Avatar

Join Date: Feb 2008
Location: Greater downtown Brownsville,Kentucky
Posts: 40,095
Send a message via AIM to Barrie Send a message via Yahoo to Barrie
Quote:
Originally Posted by Ageless Stranger View Post
That looks like my kinda hill!


Does look like fun doesn't it?
__________________
2006 Unlimited Soft Top


Skillfully disguised as a responsible adult


Barrie is offline   Quote Quick Reply
Old 02-20-2011, 09:18 PM   #11
Jeeper

jdhallissey's Avatar

Join Date: Aug 2008
Location: Gurnee,IL
Posts: 5,104
Send a message via AIM to jdhallissey
NSFW(Language)


They let you do this also. Without lockers this is un-passable. I had fun with this one.
__________________
Know nothing SPEAK on everything

Quote:
Originally Posted by ccain View Post
Isn't the JK just a rebodied PT Cruiser?!

Quote:
Originally Posted by coyote_94yj
Just a few more inches Red. You can take it.


If you haven't gotten more out of the insurance company than you deserve, then you haven't screwed them nearly as much as they have been screwing you for the past xx years.
jdhallissey is offline   Quote Quick Reply
Old 02-20-2011, 09:18 PM   #12
The Bad Guy

WF Supporting Member

daggo66's Avatar

Join Date: May 2009
Location: NJ exile living in Baltimore
Posts: 22,119
Look at the tracks. Some people turned around.
__________________
Tom

"I've got two things in this world, my balls and my word and I don't break them for no one."
daggo66 is offline   Quote Quick Reply
Old 02-20-2011, 09:19 PM   #13
Jeeper

Join Date: Jan 2011
Posts: 82
Quote:
Originally Posted by joe002 View Post
They helped getting up this hill - especially where you see all of the tire marks (with lockers you just crawl up the first hill, without thereís some tire spin required):
In my area, a hill like this would usually be covered with sharp, jagged rocks. Lockers help reduce sliced tires and flats by getting power to the ground on all 4 wheels thus reducing spin.

Also, going down a straight, steep hill will be easier and more controllable with lockers if your using engine braking.,as it allows all 4 tires for traction.

Some here will say you don't need them but they have their place and are yet another tool in your arsenal that you may have to pull out one day.
wsettle is offline   Quote Quick Reply
Old 02-20-2011, 09:20 PM   #14
UConn Husky

WF Supporting Member

Grog's Avatar

Join Date: Nov 2010
Location: Bentonville, AR
Posts: 422
Images: 6
There are three types of differentials - open, limited slip, and locking.

Open differentials drive one wheel on the axle

Limited slip can drive either wheel on the axle; one one loses traction power will go to the other wheel

A locking differential ensures both wheels turn at the same rate as the differential carrier. You can have automatic or selectable lockers. With selectable lockers, the differential can be operated as either open or locked.

A locked differential gives maximum traction, but unless you play really hard off road you don't need it
Grog is offline   Quote Quick Reply
Old 02-20-2011, 09:30 PM   #15
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792
Quote:
Originally Posted by Grog View Post
A locked differential gives maximum traction, but unless you play really hard off road you don't need it
I just had ARBs installed in both of my axles.
Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 09:37 PM   #16
Jeeper

joe002's Avatar

Join Date: Nov 2010
Location: Phoenix, AZ
Posts: 1,186
Quote:
Originally Posted by Ageless Stranger View Post
That looks like my kinda hill!

Quote:
Originally Posted by Barrie in Utah View Post
Does look like fun doesn't it?

Quote:
Originally Posted by daggo66 View Post
Look at the tracks. Some people turned around.

Yeah, it's a fun hill! Daggo - good eye, yeah some drive up to the first hill and try it but canít make it up without lockers (some do make it without lockers), or get out and look up then turn around. I must admit, the first time I saw it a few years ago I didnít even try - mainly because I was still stock and didnít have the confidence and was worried about the rocks up top which are hard to see in the pic. This last year we ran the trail again, but had to do it this time.

Quote:
Originally Posted by wsettle View Post
In my area, a hill like this would usually be covered with sharp, jagged rocks. Lockers help reduce sliced tires and flats by getting power to the ground on all 4 wheels thus reducing spin...


The control is nice. There are some rocks near the top, but they have been worn down a bit from tire spin...
joe002 is offline   Quote Quick Reply
Old 02-20-2011, 09:49 PM   #17
MTH
Jeeper

MTH's Avatar

Join Date: Oct 2010
Location: North Carolina
Posts: 8,553
While we're talking basic locker-tech, can someone opine on whether a selectable locker can be installed on a limited slip differential?

It has the feel of something where the technologies might work against each other, but it would certainly be a nice set up.
__________________
Mike
2010 JKU "Mountain" Edition
TeraFlex 2.5" Coil Lift : Old Man Emu Nitrocharger Shocks : 33x12.5R15 Goodyear DuraTracs : 15x8 Black Rock 909s : Other Stuff . . .
MTH is offline   Quote Quick Reply
Old 02-20-2011, 10:13 PM   #18
Member

Join Date: Feb 2011
Posts: 114
Quote:
Originally Posted by ncossey View Post
Not to be rude, but if you dont know what they are, you will probably never miss them or need them.
Actually, being fair and objective, your response to him, is brilliant.

ARBs forever, F and R!

Thank you,

Robert
Robert_Stephens is offline   Quote Quick Reply
Old 02-20-2011, 10:18 PM   #19
Jeeper

Ageless Stranger's Avatar

Join Date: Apr 2010
Posts: 26,792
Quote:
Originally Posted by Robert_Stephens View Post
Actually, being fair and objective, your response to him, is brilliant.

ARBs forever, F and R!

Thank you,

Robert
So you were born with the knowledge of what a locking differential is and what it does, therefore you have use for them, but someone who doesn't currently know what one is will never have use for one?
Ageless Stranger is offline   Quote Quick Reply
Old 02-20-2011, 10:19 PM   #20
Member

Join Date: Feb 2011
Posts: 114
Quote:
Originally Posted by MTH View Post
While we're talking basic locker-tech, can someone opine on whether a selectable locker can be installed on a limited slip differential?

It has the feel of something where the technologies might work against each other, but it would certainly be a nice set up.
For the ARB, the way it is set up, you would not need a limited slip. Install the ARB (basically a locked spool when engaged), in each end of your rig and use as needed. It is truly the ultimate. This is my 15th year with them and they are virtually awesome in every way in VEX.

Best,

Robert
Robert_Stephens is offline   Quote Quick Reply
Old 02-20-2011, 10:30 PM   #21
Drives by Braille

WF Supporting Member

AzTJ's Avatar

Join Date: Dec 2006
Location: For-8-Oh!
Posts: 13,621
Quote:
Originally Posted by MTH View Post
While we're talking basic locker-tech, can someone opine on whether a selectable locker can be installed on a limited slip differential?

It has the feel of something where the technologies might work against each other, but it would certainly be a nice set up.
A selectable locker (ie ARB) replaces the carrier, so the LSD would go away. Selectable lockers are either OPEN or LOCKED... nothing in between.
AzTJ is offline   Quote Quick Reply
Old 02-20-2011, 10:33 PM   #22
MTH
Jeeper

MTH's Avatar

Join Date: Oct 2010
Location: North Carolina
Posts: 8,553
Quote:
Originally Posted by Robert_Stephens

For the ARB, the way it is set up, you would not need a limited slip. Install the ARB (basically a locked spool when engaged), in each end of your rig and use as needed. It is truly the ultimate. This is my 15th year with them and they are virtually awesome in every way in VEX.

Best,

Robert
No doubt lockers have their place and are the best for what they're for, but what I'm thinking of is having the limited slip for heavy snow falls while the lockers would be an off road only type of item.

For example, even in bad weather I wouldn't want to lock my axles at the outset of a 45 minute drive home from work where sometimes I might have full traction but other times may not. I'd think a limited slip would be better for those purposes.

Of course, at the moment I have neither, so it's all just thinking about the future at this point.
__________________
Mike
2010 JKU "Mountain" Edition
TeraFlex 2.5" Coil Lift : Old Man Emu Nitrocharger Shocks : 33x12.5R15 Goodyear DuraTracs : 15x8 Black Rock 909s : Other Stuff . . .
MTH is offline   Quote Quick Reply
Old 02-20-2011, 10:35 PM   #23
MTH
Jeeper

MTH's Avatar

Join Date: Oct 2010
Location: North Carolina
Posts: 8,553
Quote:
Originally Posted by AzTJ

A selectable locker (ie ARB) replaces the carrier, so the LSD would go away. Selectable lockers are either OPEN or LOCKED... nothing in between.
Thanks, that's what I suspected. Still makes me a little sad. :,(
__________________
Mike
2010 JKU "Mountain" Edition
TeraFlex 2.5" Coil Lift : Old Man Emu Nitrocharger Shocks : 33x12.5R15 Goodyear DuraTracs : 15x8 Black Rock 909s : Other Stuff . . .
MTH is offline   Quote Quick Reply
Old 02-20-2011, 10:37 PM   #24
Jeeper

joe002's Avatar

Join Date: Nov 2010
Location: Phoenix, AZ
Posts: 1,186
Quote:
Originally Posted by MTH View Post
...but what I'm thinking of is having the limited slip for heavy snow falls while the lockers would be an off road only type of item...
We do have a "computerized" limited slip with the BLD, which gives you limited slip like capability.

From the Owners Manual:
TCS (Traction Control System)
This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) to provide enhanced acceleration and stability. A feature of the TCS system functions similar to a limited slip differential and controls the wheel spin across a driven axle. If one wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning wheel. This will allow more engine torque to be applied to the wheel that is not spinning. This feature remains active even if TCS and ESP are in either the “Partial Off” or “Full Off” modes. Refer to “ESP (Electronic Stability Program)” in this section.

joe002 is offline   Quote Quick Reply
Old 02-20-2011, 10:47 PM   #25
MTH
Jeeper

MTH's Avatar

Join Date: Oct 2010
Location: North Carolina
Posts: 8,553
Quote:
Originally Posted by joe002
We do have a "computerized" limited slip with the BLD, which gives you limited slip like capability.

. . . . A feature of the TCS system functions similar to a limited slip differential and controls the wheel spin across a driven axle. If one wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning wheel. This will allow more engine torque to be applied to the wheel that is not spinning.
Holy cow, I had no idea. I'm not too crazy about the Jeep tweaking my brakes while I'm driving (especially in bad weather), but even still, that's pretty cool.
__________________
Mike
2010 JKU "Mountain" Edition
TeraFlex 2.5" Coil Lift : Old Man Emu Nitrocharger Shocks : 33x12.5R15 Goodyear DuraTracs : 15x8 Black Rock 909s : Other Stuff . . .
MTH is offline   Quote Quick Reply
Old 02-20-2011, 11:01 PM   #26
Jeeper

joe002's Avatar

Join Date: Nov 2010
Location: Phoenix, AZ
Posts: 1,186
Quote:
Originally Posted by MTH View Post
Holy cow, I had no idea. I'm not too crazy about the Jeep tweaking my brakes while I'm driving (especially in bad weather), but even still, that's pretty cool.

Yeah, it can actually work rather well and maybe so well in fact that you haven't noticed it working for you. You can usually feel it kick in when one of your tires starts to slip.
joe002 is offline   Quote Quick Reply
Old 02-20-2011, 11:16 PM   #27
Jeeper

ncossey's Avatar

Join Date: Aug 2010
Location: Fort Smith, AR
Posts: 1,180
Quote:
Originally Posted by daggo66

Now if I said that all heck would break loose.
Hahahah I love barries response to this. I think he has a soft spot for me!

Seriously, if you want to learn about lockers, the best way is to find someone with a jeep, and go riding with them. Have them do somethig challenging unlocked, then do it again locked. You will see a difference.
__________________
There are very few vehicles that can be defined as "made for offroad". Unfortunately, the Wrangler can definitely be defined as "made for offroad" by its inability to handle well on road
ncossey is offline   Quote Quick Reply
Old 02-20-2011, 11:21 PM   #28
Jeeper

Teco210wrangler's Avatar

Join Date: Sep 2010
Posts: 43
Cool man thanx everyone I'm learning allot from u guys.... Hey gotta start and learn someday right ... THANX!
Teco210wrangler is offline   Quote Quick Reply
Old 02-20-2011, 11:22 PM   #29
Jeeper

joe002's Avatar

Join Date: Nov 2010
Location: Phoenix, AZ
Posts: 1,186
I found this video. You can see when the camera guy moves to the passenger side that the tracks show both tires were spinning, and when he tries again the driver side tire is spinning the whole time and the passenger side starts out slow but spins right along with the drivers side.
joe002 is offline   Quote Quick Reply
Old 02-20-2011, 11:24 PM   #30
Jeeper

ncossey's Avatar

Join Date: Aug 2010
Location: Fort Smith, AR
Posts: 1,180
Quote:
Originally Posted by Ageless Stranger

So you were born with the knowledge of what a locking differential is and what it does, therefore you have use for them, but someone who doesn't currently know what one is will never have use for one?
Thats not the point I was trying to get across, man you guys need some backbone.

The point I was trying to get at is that there are tons of people that come on here and get advice from people that pretend to be experts then find they didnt need it, or it wasnt right. Lockers arent cheap, they can destroy your ride if not used properly, and 80% of the time, not needed offroad. A good set of aired down tires, proper gearing, and an aware driver is much more successful than someone who is new offroad in a 37 thousand dollar toy who doesnt know how to utilize 10 thousand dollars worth of equipment on it.

On that note, there are literally thousands of online references about the benefits and negatives of lockers, how they work, and how they should be used in each application. Last time I checked, the information on wikipedia is fairly accurate and would be a good starting point. Like i said earlier though, the best way to learn about locking out, is to go jeeping with someone who is experienced with them.

__________________
There are very few vehicles that can be defined as "made for offroad". Unfortunately, the Wrangler can definitely be defined as "made for offroad" by its inability to handle well on road
ncossey is offline   Quote Quick Reply
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the Jeep Wrangler Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
If you do not want to register, fill this field only and the name will be used as user name for your post.
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid email address for yourself.
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off


Similar Threads
Thread Thread Starter Forum Replies Last Post
Four Wheel Drive and Lockers Zeddjb JK General Discussion Forum 0 08-08-2010 06:23 PM
Lockers, performance, uninstall? Flyguychad TJ General Discussion Forum 20 05-15-2010 12:30 AM
Aussie Lockers?? Anything Cheaper than ARB? Timberman TJ General Discussion Forum 15 11-12-2008 06:07 PM
Calling all gear heads!! Lockers!! Timberman TJ General Discussion Forum 13 10-04-2008 11:48 AM
Lockers? whitebuffalo General Jeep Discussion 16 07-05-2005 05:22 PM


» Vendor Spotlight (Deals & More)
Jeep Parts - Jeep Wheels - Jeep Soft Tops
» Recent Threads

» Popular Tags
2013 2014 advice audio axle bestop build bumper camping clutch doors electrical engine exhaust fenders for sale frame gears hard top hardtop help advice install jeep jeep tj jeep wrangler jeep yj jku leak led lift lift advice lift kit lights manual mods mud newbie noise oem parts radiator radio rims rubicon rust sahara shocks soft top speakers sport steering stereo stock subwoofer suspension suspension lift teraflex tire tires top transfer case transmission unlimited upgrade wheels wheels and tires winch wiring wrangler wrangler tj
» Network Links
»Jeep Parts
» Featured Product

All times are GMT -5. The time now is 08:18 AM.



Jeepģ, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
