Heat & Air?

Newbie here, I just realized my 99 has a major issue with the blower. I thought it was normal for the little difference in 1-4 on the fan settings until I got in my brother-in-laws 98. Any help on what to check first? Oh and after no wave-backs for nearly two months, got my first today! Now I feel accepted

legman68 is offline   Quote Quick Reply
Old 05-09-2010, 08:55 PM   #2
Jeeper

jpdocdave's Avatar

Join Date: Mar 2008
Location: beach park, il
Posts: 8,162
Images: 7
common problems in the blower motor resistor, give a little more description of how the blower is working.

__________________
"The danger to America is not Barack Obama but a citizenry capable of entrusting a man like him with the Presidency. It will be far easier to limit and undo the follies of an Obama presidency than to restore the necessary common sense and good judgment to a depraved electorate willing to have such a man for their president."
http://mybroadband.co.za/photos/data...re_cowbell.gif
jpdocdave is offline   Quote Quick Reply
Old 05-09-2010, 09:10 PM   #3
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Well, it may not be doing anything. If your idling, very little comes out, once moving you get some flowing, but like I mentioned, 1 or 4, little difference.
legman68 is offline   Quote Quick Reply
Old 05-09-2010, 09:39 PM   #4
Jeeper

jpdocdave's Avatar

Join Date: Mar 2008
Location: beach park, il
Posts: 8,162
Images: 7
hmm, its possible that someone installed an aftermarket replacement blower motor, and wired it backwards. some replacement parts require splicing in the connector, if its wired backwards it will spin backwards and move very little air. look at the connector and see if there's any splices by the blower motor.
__________________
"The danger to America is not Barack Obama but a citizenry capable of entrusting a man like him with the Presidency. It will be far easier to limit and undo the follies of an Obama presidency than to restore the necessary common sense and good judgment to a depraved electorate willing to have such a man for their president."
http://mybroadband.co.za/photos/data...re_cowbell.gif
jpdocdave is offline   Quote Quick Reply
Old 05-09-2010, 09:50 PM   #5
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Remember, I'm a newbie, that goes for mechanics in general. Where exactly am I looking?
legman68 is offline   Quote Quick Reply
Old 05-09-2010, 10:07 PM   #6
Jeeper

jpdocdave's Avatar

Join Date: Mar 2008
Location: beach park, il
Posts: 8,162
Images: 7
i'd suggest getting a good service manual, and the blower motor is under the dash on the right side. you can also post pics and we will answer and help that way to.
__________________
"The danger to America is not Barack Obama but a citizenry capable of entrusting a man like him with the Presidency. It will be far easier to limit and undo the follies of an Obama presidency than to restore the necessary common sense and good judgment to a depraved electorate willing to have such a man for their president."
http://mybroadband.co.za/photos/data...re_cowbell.gif
jpdocdave is offline   Quote Quick Reply
Old 05-09-2010, 10:40 PM   #7
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
I've got a Haynes, but that doesn't help much. Do you mean one from Jeep? I'm just not sure what to look for, everything under there looks factory.
legman68 is offline   Quote Quick Reply
Old 05-09-2010, 11:23 PM   #8
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
If setting 4 is out on the turn control well.....it's not the resistor. Setting 4 does NOT go through the blower reostate "resistoer". It pulls straight 12v power...thats the problem..jeep had a brain fart there.

And yep, VERY common issue. Saidly the fix is some relays and a new control box if the melting is too bad. Yep I said melting.

Pull the heater/ac control panel out and look at the back of it where the wire connector is connected on the far right side. It will have 3 wires. One which is a little larger and green. Check for melting. Look close. Also at the other connectors for any melting.

"""""to remove heater control box for inspection""""

Remove the defrost vent cover , pull up on the far side not the middle. pops right off.
Remove the ashtray. Open it and push down on the tab on the inside and slide out.
Remove the screw behind the ashtray.
At the top of the center bezel where you removed the defrost vent cover,,,remove the 2 screws that hold on the bezel. Pull the whole center bezel off..pull right off.
The heater/ac controls will have a few screws holding it on...take them off.
Poof your done. and can inspect the controls.

READ through this WHOLE thread. And the links in post #10.
CLICK ME---->>>>http://www.wranglerforum.com/f5/heat...rol-16174.html

If you have any more questions let us know.
distortedtj is offline   Quote Quick Reply
Old 05-10-2010, 01:21 AM   #9
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Got my job for tomorrow, I'll let you know. Thanks
legman68 is offline   Quote Quick Reply
Old 05-10-2010, 01:24 AM   #10
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
No problem bud. The problem is common. The melting could be easy to see or you may have to look hard.

If you need any more help let us know bud.
distortedtj is offline   Quote Quick Reply
Old 05-10-2010, 09:24 PM   #11
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Didn't need to look hard at all. The control switch is toast and so is the plug. I assume i need to buy both? I checked out the link on that resistor, I assume your telling me to do that too?
legman68 is offline   Quote Quick Reply
Old 05-10-2010, 09:31 PM   #12
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
Quote:
Originally Posted by legman68 View Post
Didn't need to look hard at all. The control switch is toast and so is the plug. I assume i need to buy both? I checked out the link on that resistor, I assume your telling me to do that too?
Ha, yep it's common. Yep you will need to do "that",,,adding the relays to limit the power going to the switch to prevent it from melting in the future. If not...well it's going to melt again.

You can pick the relays up at any auto parts store. As for the wire and connectors.

For the "PLUG'....good luck jeep will only sell you a complete harness. Remedy for it is to use male spade connectors with the protectors on them.

For the control box you will either have to go through the dealership for the control box. Daveysjeeps.com can sell you a used one but the price they want for them you would be better off with a new from the dealer.
distortedtj is offline   Quote Quick Reply
Old 05-10-2010, 09:39 PM   #13
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Do I need the whole control box, or just the blower switch? Found that for $15 new. Will the parts place know what kind of relays I need? Any specs I need to give them. Very cool to get help like this!
legman68 is offline   Quote Quick Reply
Old 05-10-2010, 09:55 PM   #14
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
30 amp relay.
distortedtj is offline   Quote Quick Reply
Old 05-10-2010, 10:11 PM   #15
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Thanks Again!
legman68 is offline   Quote Quick Reply
Old 05-11-2010, 02:16 AM   #16
Jeeper

meyers's Avatar

Join Date: Apr 2009
Location: Dover, New Hampshire
Posts: 738
I have read different things on this melting, is this common? My 2002 has never had an issue with this, and last time I looked the plug was fine. I did change the resistor out last year but after 8 years of no trouble I am not going to complain!!
meyers is offline   Quote Quick Reply
Old 05-11-2010, 02:20 AM   #17
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
Quote:
Originally Posted by meyers View Post
I have read different things on this melting, is this common? My 2002 has never had an issue with this, and last time I looked the plug was fine. I did change the resistor out last year but after 8 years of no trouble I am not going to complain!!
Common...Yes mainly for the older TJ's.
The blower resistor is most common. For all TJ models. Exspecially the newer model TJ's.
distortedtj is offline   Quote Quick Reply
Old 05-11-2010, 10:00 PM   #18
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Ok dis, changed the switch, and only high works. Which i get means the switch is actually not doing anything, straight thru from battery. But at least it's doing something. From that past thread, could it be the resistor down by the blower?
legman68 is offline   Quote Quick Reply
Old 05-11-2010, 10:11 PM   #19
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
^^^ Yes. $18 from the dealer. Don't get one from the chain auto store like autozone...they have been having issues with crappy blower resistors and other electric parts lately.
distortedtj is offline   Quote Quick Reply
Old 05-11-2010, 10:13 PM   #20
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
Quote:
Originally Posted by legman68 View Post
Ok dis, changed the switch, and only high works. Which i get means the switch is actually not doing anything, straight thru from battery. But at least it's doing something. From that past thread, could it be the resistor down by the blower?
Did you fix the melting issue??? IE, replace connector/wire relays? If you don't it will melt it again.
distortedtj is offline   Quote Quick Reply
Old 05-11-2010, 10:14 PM   #21
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
OK got tomorrows job!
legman68 is offline   Quote Quick Reply
Old 05-11-2010, 10:16 PM   #22
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
I must admit I did not. I stopped at local parts store and there was a mile long line. I will though! Might as well do it tomorrow.
legman68 is offline   Quote Quick Reply
Old 05-11-2010, 10:19 PM   #23
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
good luck bud let us know if you have any issues.
distortedtj is offline   Quote Quick Reply
Old 05-12-2010, 10:39 AM   #24
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
18? Holy crap, 74 from dealer! Autozone for 41!
legman68 is offline   Quote Quick Reply
Old 05-12-2010, 12:43 PM   #25
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Right thing?

Guy at parts store had no idea what i was explaining to him.So this is what i ended up with. If it's right, do they go on all the leads that go into that switch?
legman68 is offline   Quote Quick Reply
Old 05-12-2010, 12:51 PM   #26
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Oops!

Wow! Thats a big picture
legman68 is offline   Quote Quick Reply
Old 05-12-2010, 01:19 PM   #27
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
Quote:
Originally Posted by legman68 View Post
Guy at parts store had no idea what i was explaining to him.So this is what i ended up with. If it's right, do they go on all the leads that go into that switch?
Um,. nope.. that is a fuse link. It's so you can add a fuse into a wire line. Not a relay.

Here is what you are looking for. Most auto stores will have them buy the light bulbs or beside their fog lights.....

distortedtj is offline   Quote Quick Reply
Old 05-12-2010, 01:24 PM   #28
Nerf gun assassin

WF Supporting Member
::WF Administrator::

distortedtj's Avatar

Join Date: May 2005
Location: yep right there.
Posts: 21,294
Send a message via Yahoo to distortedtj
Quote:
Originally Posted by legman68 View Post
18? Holy crap, 74 from dealer! Autozone for 41!
WOW, they went up in the last year or two!! I just looked.

Here you go for $35....

BWD RU1046 - Blower Motor Resistor | O'Reilly Auto Parts
distortedtj is offline   Quote Quick Reply
Old 05-12-2010, 04:34 PM   #29
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Uhhh...I really am a smart guy, but feeling pretty ignorant about now. The article stated they put one on each speed. How does that work? I got 5 wires going into the switch, each one is a speed, with one common? How do the relays tie in?
legman68 is offline   Quote Quick Reply
Old 05-12-2010, 08:46 PM   #30
Jeeper

legman68's Avatar

Join Date: Apr 2010
Location: NoCal
Posts: 369
Just when I thought I was done. Get home, put in the resistor, same thing, only high speed. Plus another guy at parts store was useless about the relays. I guess I'll find those online.

legman68 is offline   Quote Quick Reply
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the Jeep Wrangler Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
If you do not want to register, fill this field only and the name will be used as user name for your post.
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid email address for yourself.
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off


Similar Threads
Thread Thread Starter Forum Replies Last Post
98 TJ too much heat!!! Oldfart TJ Tech Forum 15 07-06-2010 11:10 PM
Any HVAC technicians here? mrcarcrazy Off-Topic 19 02-05-2010 02:23 PM
Little Heat skidoomzx TJ Tech Forum 1 01-31-2010 02:02 PM
87 jeep wrangler heat issues. 94cummins YJ Tech Forum 9 12-30-2009 07:10 PM
heat abecker TJ General Discussion Forum 4 01-28-2009 10:56 AM



» Featured Product

All times are GMT -5. The time now is 08:32 AM.



Jeep®, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
