CB antenna mounting location

Is anyone using a firestik or wilson tunable cb antenna mounted on their rear tire carrier? Any issue with the grounding? I want to install it on mine but not sure if the tire carrier will provide sufficient grounding. Pics will help...thanks.

3' Wilson or 3' firestik tunable antenna?

__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-14-2011, 04:43 PM   #2
Jeeper

WVRUBI's Avatar

Join Date: Jan 2011
Location: WV
Posts: 170
Im thinking of putting mine there. There is a pretty good write up in this months issue of JP mag. about cb and antenna installation. You can read it online.

__________________
"that sure is a nasty habit you got there"
WVRUBI is offline   Quote
Old 02-14-2011, 04:46 PM   #3
JSY
Jeeper

JSY's Avatar

Join Date: Jul 2010
Location: Owasso,OK
Posts: 413
I don't have one but if I get one I plan to mount it identical to the stock radio antenna just on the other side. I haven't seen many done this way...
JSY is offline   Quote
Old 02-14-2011, 06:13 PM   #4
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
Quote:
Originally Posted by WVRUBI View Post
Im thinking of putting mine there. There is a pretty good write up in this months issue of JP mag. about cb and antenna installation. You can read it online.

Thank you, I will look it up.
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-14-2011, 06:15 PM   #5
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
Quote:
Originally Posted by JSY View Post
I don't have one but if I get one I plan to mount it identical to the stock radio antenna just on the other side. I haven't seen many done this way...

That is a good idea also. Mine is constantly whipping my roof rack and annoyed the crap out of me so I zip tied it to my roof rack support post. This may happen to me if I mount the cb antenna there also.
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-14-2011, 06:35 PM   #6
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
Quote:
Originally Posted by WVRUBI View Post
Im thinking of putting mine there. There is a pretty good write up in this months issue of JP mag. about cb and antenna installation. You can read it online.

I can't seem to find that article in JP. Do you by any chance have the link to it?

Thanks
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-14-2011, 07:28 PM   #7
Jeeper

WVRUBI's Avatar

Join Date: Jan 2011
Location: WV
Posts: 170
I dont have a link but im looking at the mag right now and the article is called "chatting up the boonies" cb install how-tos. Hope that helps you find it.
__________________
"that sure is a nasty habit you got there"
WVRUBI is offline   Quote
Old 02-14-2011, 08:59 PM   #8
Jeeper

computeruser's Avatar

Join Date: May 2010
Location: East Lansing, MI
Posts: 811
It won't have enough grounding by itself. I have a 5' (6'?) Wilson there, which works great, except in parking structures and at the drive-thru carwash. I ran a separate ground wire back from the mount into the vehicle and grounded to the a rear seat bracket bolt on the fenderwell. All my wires run through the grommet where the third brakelight wires used to run, back before the third brakelight went in the shitcan.
computeruser is offline   Quote
Old 02-14-2011, 09:08 PM   #9
Wheelin' and Dealin'

WF Supporting Member

OsageJeep's Avatar

Join Date: Nov 2010
Location: Osage, Arkansas
Posts: 1,515
Send a message via Skype™ to OsageJeep
I was wondering if anybody is running the flush mount 4" LEDs and where they have their CB antenna mounted. I was planning on buying the Teraflex antenna mount that goes behind the driver side taillight but I have been contemplating going to the flush-mounts so I was wondering where people who had them mounted their CB antenna?
__________________
I love my country, I love my guns, I love my family, I love the way it is now, and anybody that tries to change it has to come through me, that should be all of our attitudes, cause this is America
OsageJeep is offline   Quote
Old 02-15-2011, 03:31 AM   #10
Jeeper

kpool's Avatar

Join Date: Feb 2010
Location: gainesville /ga/30506
Posts: 300
Send a message via AIM to kpool
http://www.walcottcb.com/firestik-m2-side-body-mount-p-298.html

[/IMG]
[/IMG]
kpool is offline   Quote
Old 02-15-2011, 10:12 AM   #11
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 8,369
i say keep it on the tailgate. that way you'll need less wire and less chance of pinching the wire.

heres what i did:

UnlimitedLJ04 is offline   Quote
Old 02-15-2011, 10:20 AM   #12
Jeeper

kpool's Avatar

Join Date: Feb 2010
Location: gainesville /ga/30506
Posts: 300
Send a message via AIM to kpool
With this mount the wire is connected on the other side and it don't have to be grounded.

kpool is offline   Quote
Old 02-15-2011, 12:11 PM   #13
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
Quote:
Originally Posted by computeruser View Post
I ran a separate ground wire back from the mount into the vehicle and grounded to the a rear seat bracket bolt on the fenderwell.

Do you have a picture of the separate ground wire? I might have to do this and not sure how it is done.

Thanks
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-15-2011, 12:57 PM   #14
Jeeper

Loic's Avatar

Join Date: Jun 2009
Location: LAS VEGAS
Posts: 794
i mounted my antena on the front fender, gounded it to the frame. but i have a wilson K2500 (whip) (i think its what it is...lol) i didnt want a fiberglass antena as i think they would break easier, and didnt want to have it stuck in the back because of the reception.


correction, its a 2000.

Loic is offline   Quote
Old 02-15-2011, 09:11 PM   #15
Jeeper

neverfastenough1's Avatar

Join Date: Nov 2010
Location: Savannah, Ga
Posts: 925
If you run a separate ground, it can't be a small wire. A ground strap is recommended (braided). I made a copy of the mount that goes behind the light and ran a braided strap through a grommet in the tail light husing to a mount nut for the light. It was already grounded, but that was to make sure it was a good one.
neverfastenough1 is offline   Quote
Old 02-15-2011, 09:34 PM   #16
Jeeper

neverfastenough1's Avatar

Join Date: Nov 2010
Location: Savannah, Ga
Posts: 925
Quote:
Originally Posted by kpool View Post
With this mount the wire is connected on the other side and it don't have to be grounded.

I believe the lower lug is where you connect the ground to. Its true that this is a NGP antenna, but that is different than a ground. An NGP antenna kit like this one is good for a Wrangler type vehicle. Your rf signal goes straight down til it hits the ground plane. Then it emits out in the direction of the plane. On the rear of the vehicle, you will get a better signal going forward than back because there is no ground plane behind the antenna. One of these NGP antennas eliminates the need for a ground plane. You can also eliminate the need for a ground plane by using two antennas. that pic up there with the two antenna mount on the tailgate is wrong, though. You don't want them to be that close together. When you have two antennas, the signal goes more front and back, unlike one antenna where it goes 360 degrees.
neverfastenough1 is offline   Quote
Old 02-16-2011, 10:56 AM   #17
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
This is what I have ordered yesterday. I wonder if this will work.

1 x KCB5SS Stainless Steel Lug Stud Antenna Mount (KCB5SS)
1 x SS3H Heavy Duty Stainless Steel Springs (SS3H)
1 x FS3 3-Foot Tunable Tip CB Antenna (FS3) Color Black
1 x 18 Foot RG8X Coax with Weather Boot (18S8XCN13)
1 x ESP20 20-Watt External Speaker (ESP20)
1 x Uniden 520xl pro cb

Thanks
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-16-2011, 11:07 AM   #18
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 36,282
I used a piece of 1"x4"x1/8" stainless steel to mount my first CB antenna to the spare tire carrier. The spare tire mounting surface it mounts to slopes downward slightly so I simply gave the stainless steel a slight twist so the antenna would be vertical.
Attached Thumbnails
Click image for larger version

Name:	antennaMount.jpg
Views:	176
Size:	55.0 KB
ID:	38240
__________________
When you have a choice, buy American.

Jerry Bransford is online now   Quote
Old 02-16-2011, 11:45 AM   #19
Jeeper

oIIIIIIo's Avatar

Join Date: Sep 2010
Location: Bay Area, CA
Posts: 684
Quote:
Originally Posted by Jerry Bransford View Post
I used a piece of 1"x4"x1/8" stainless steel to mount my first CB antenna to the spare tire carrier. The spare tire mounting surface it mounts to slopes downward slightly so I simply gave the stainless steel a slight twist so the antenna would be vertical.

Jerry~ did it provide sufficient amount of grounding or you have to install a separate grounding wire? I am mounting mine to a Body Armor swing out tire carrier which has an antenna mount already. I am not sure if this will work.

Thanks-Chio
__________________
2000 TJ, I6, Auto
oIIIIIIo is offline   Quote
Old 02-16-2011, 12:03 PM   #20
Jeeper

Join Date: Aug 2010
Location: IL
Posts: 1,113
Quote:
Originally Posted by UnlimitedLJ04 View Post
i say keep it on the tailgate. that way you'll need less wire and less chance of pinching the wire.

heres what i did:

What if your tail gate works Like the CJ's not the swing type like the TJ's then we gotta mount to the body.
97flexy is offline   Quote
Old 06-08-2011, 05:28 PM   #21
Jeeper

WF Supporting Member

samnmax's Avatar

Join Date: Nov 2010
Location: Kansas
Posts: 112
Has anybody ever tried mounting the antenna bracket on the side of the tub, like right above/in front of the gas cap? I'm installing a dual antenna setup, but really don't want to have to pull the antennas off whenever I want to put my hard top back on. I was thinking about drilling through the side of the tub, but haven't seen anybody else do it that way...
__________________
For every action, there is an equal and opposite government program.

Artificial intelligence is no match for natural stupidity.

2003 TJ Sahara with 31" Dunflop Mud Rovers, Ford 8.8 Rear diff with ARB locker, 3.5" DPG Ultimate Lifts.
samnmax is offline   Quote
Old 06-08-2011, 08:09 PM   #22
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 36,282
If you offroad, having the antenna on the side of the Jeep would make the antenna highly vulnerable to being damaged.
__________________
When you have a choice, buy American.

Jerry Bransford is online now   Quote
Old 06-08-2011, 11:08 PM   #23
Jeeper

WF Supporting Member

samnmax's Avatar

Join Date: Nov 2010
Location: Kansas
Posts: 112
Okay, what about cons/benefits for having them mounted:
a. right above the taillights
or
b. within a foot of each other, mounted on the stock tire carrier

I'm trying to squeeze as much signal as I can out of my setup (twin 4' Firestiks running into a Uniden 538W).
__________________
For every action, there is an equal and opposite government program.

Artificial intelligence is no match for natural stupidity.

2003 TJ Sahara with 31" Dunflop Mud Rovers, Ford 8.8 Rear diff with ARB locker, 3.5" DPG Ultimate Lifts.
samnmax is offline   Quote
Old 06-09-2011, 06:02 AM   #24
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 939
tailhole is offline   Quote
Old 06-09-2011, 08:21 AM   #25
Jeeper

Join Date: May 2010
Posts: 2,221
Quote:
Originally Posted by JSY View Post
I don't have one but if I get one I plan to mount it identical to the stock radio antenna just on the other side. I haven't seen many done this way...
I had problems mounting it there; it could have been the way I wired it, something specific about my Jeep, who knows, but I got terrible interference from the engine when I mounted it there. I ended up getting a teraflex mount for behind my taillight. All is good now. I know several people who have them mounted on their tire carriers will good results as well.
geiman is offline   Quote
Old 06-09-2011, 02:15 PM   #26
Jeeper

sparky's Avatar

Join Date: Oct 2009
Location: Phila
Posts: 2,120
Click image for larger version

Name:	100_1362a.jpg
Views:	282
Size:	182.4 KB
ID:	52828

I'm using tub mounted on the sides with a ball mount. I have one on each side. They do not stick out past the flairs. All antennas are attached with quick disconnects, so I can change what I am doing easily. The one in the picture is too tall for trail use. That's a Hustler CGT-144. Over 7' by itself, it works well but it hits stuff overhead. (I'ts also 2M not CB). Point is, I think a body mount is fine. It's strong, no question on ground bonding. It could get snagged, and just grit your teeth when you break out the hole saw.

I have two, if you only do one, put it on the drivers side, you have more overhead clearance towards the middle of the trail if you are riding on the right side.
sparky is offline   Quote
Old 06-09-2011, 07:12 PM   #27
Jeeper

NewYJOwner's Avatar

Join Date: Oct 2010
Location: Central Michigan
Posts: 613
Quote:
Originally Posted by samnmax View Post
Has anybody ever tried mounting the antenna bracket on the side of the tub, like right above/in front of the gas cap? I'm installing a dual antenna setup, but really don't want to have to pull the antennas off whenever I want to put my hard top back on. I was thinking about drilling through the side of the tub, but haven't seen anybody else do it that way...
I mounted a single tunable fiberglass antenna on the passenger side of my YJ tub, haven't had issues with trail damage yet.

NewYJOwner is offline   Quote
Old 06-09-2011, 08:22 PM   #28
Jeeper

Scoob's Avatar

Join Date: Aug 2005
Location: Iowa
Posts: 1,790
Quote:
Originally Posted by samnmax View Post
Okay, what about cons/benefits for having them mounted:
a. right above the taillights
or
b. within a foot of each other, mounted on the stock tire carrier

I'm trying to squeeze as much signal as I can out of my setup (twin 4' Firestiks running into a Uniden 538W).
Option A
There are no benefits to this at all, only cons. Dual antennas should be not be that close to each other. They should be 9 feet apart. Anything closer and it starts driving up the SWR to the point that a single antenna (with a lower swr) would have better range.



Option B
You are going to smoke the radio.


If you want the best range for your unit get a longer better antenna (single) choose a way to increase the power output.
__________________
Scoob
Scoob is offline   Quote
Old 06-09-2011, 09:07 PM   #29
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 36,282
X2 on Scoob's advice that twin antennas won't work on a Jeep. Plus you lose the omni-directionality of a single antenna and make it directional so it only transmits well fore and aft but not to the sides.

A single antenna is fine and works well for a Jeep. I've been doing 2-way radios since the sixties and simple is normally better.
__________________
When you have a choice, buy American.

Jerry Bransford is online now   Quote
Old 06-10-2011, 06:44 AM   #30
Jeeper

Join Date: Jun 2011
Location: Northern Maine (way past the Moose !!!)
Posts: 76
I have the exact same Jeep as you. I have my antenna same side but behind the wheel well. Up here in Maine we need every bit of antenna performance we can get due to the distances.

Old Grunt is offline   Quote
Reply

Thread Tools

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off


Similar Threads
Thread Thread Starter Forum Replies Last Post
CB antenna (stock tire carrier mounting) mudslinger150 Communications and Electronics 20 01-11-2010 01:33 PM
CB antenna and jerry can location stevens243 TJ General Discussion Forum 6 10-03-2008 01:26 PM
new switch mounting location! NalinMFG TJ General Discussion Forum 0 08-29-2008 01:32 AM
Rock-It Parts TJ CB Antenna Mounting Plate - CA Unlimited Classifieds Archive 1 02-11-2008 12:17 AM
Hi-Lift Mounting Location compshooter TJ General Discussion Forum 14 02-21-2007 12:46 PM



Download our Mobile App

» Featured Product

All times are GMT -5. The time now is 02:16 AM.


User Alert System provided by Advanced User Tagging v3.1.0 (Pro) - vBulletin Mods & Addons Copyright © 2015 DragonByte Technologies Ltd.

Jeep®, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
