Help in identificaton of deifferential gear missing tooth picture

I changed the differential oil today and had alot of fine metallic matter like a glitter in the old oil. Upon cleaning and a closer inspection, I have a t\gear tooth from an unidetnefied part missing. Can anyone tell me what gear this and what would cause it? It is only one tooth which i find hard to understand how all the other teeth are not worn. If you click on the picture arrows show up pointing to the mising tooth.



Any help would be greatly appreciated.

pwbum1 is offline   Quote Quick Reply
Old 11-07-2011, 10:11 PM   #2
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 7,519
they're called spider gears. cause of the chip is the craptastic D35c axle....but really who knows why, theres a number of stupid things one can do to make that happen.

honestly, parts and labor to replace it will be more expensive then just finding a junkyard axle, but here's the kit to fix it: Dana 35 Spider Gear Kit 1.5 / Dana 35 Spider Gears (94 & NEWER)

UnlimitedLJ04 is offline   Quote Quick Reply
Old 11-08-2011, 09:24 AM   #3
Supporting Member

WF Supporting Member

BlackedOutYJ's Avatar

Join Date: Feb 2011
Location: Bonne Terre MO
Posts: 1,939
I got a full set of spider gears out of a D35 I could sell you at a good price
__________________
Help restore faith in humanity, do something nice! KCCO
BlackedOutYJ is offline   Quote Quick Reply
Old 11-08-2011, 09:27 AM   #4
Jeeper

nastyrider17's Avatar

Join Date: Jul 2010
Location: New Hampshire
Posts: 816
Just weld it up. Won't cost anything and you'll get a locker out of it too.
__________________
My 2000 TJ Build Thread <--click it
nastyrider17 is offline   Quote Quick Reply
Old 11-08-2011, 09:30 AM   #5
Electrical Guy

WF Supporting Member

deathphoenix99's Avatar

Join Date: Apr 2010
Location: Houston, TX
Posts: 2,619
Don't weld the rear end up, unless it's purely an off road rig, you'll end up breaking more than you bargain for on the road. Even off road I wouldn't want a welded rear.

Check everything else out too and make sure that broken tooth didn't get caught in any of the other gears and mess them up.
__________________
2011 RCLB Silverado, It's got the power I need.
Wiring Diagrams!
-Phil-

QUOTE:Bugsbb
"You're just about to get a bump and poke back.."
deathphoenix99 is offline   Quote Quick Reply
Old 11-09-2011, 09:58 AM   #6
Jeeper

Join Date: Dec 2010
Posts: 18
Thanks for all the info1
pwbum1 is offline   Quote Quick Reply
Old 11-09-2011, 10:04 AM   #7
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 7,519
Quote:
Originally Posted by nastyrider17 View Post
Just weld it up. Won't cost anything and you'll get a locker out of it too.
yea, cause thats a brillant idea on a daily driven D35c.
UnlimitedLJ04 is offline   Quote Quick Reply
Old 11-09-2011, 10:45 AM   #8
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 32,746
Images: 2
That chipped spider gear probably won't cause you any problem. If it does, many 4x4 shops have spider gears in their junk boxes removed during locker installations they'll give you for free if you pay them to install them. Most people who have done locker installations give them free to other Jeepers, keep your eyes open.
__________________
When you have a choice, buy American.

Jerry Bransford is offline   Quote Quick Reply
Old 11-09-2011, 11:33 AM   #9
Jeeper

nastyrider17's Avatar

Join Date: Jul 2010
Location: New Hampshire
Posts: 816
Quote:
Originally Posted by UnlimitedLJ04 View Post
yea, cause thats a brillant idea on a daily driven D35c.
I know, right.
