Old 05-31-2010, 07:03 PM   #1
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Talking Homemade Sway Bar Quick Disconnects...

After doing some wheelin at the lake yesterday I decided I needed to make a pair of quick disconnects. Went to the hardware store this morning, got the parts for under $10 and put them on.. they work great! Everybody needs to do this!

Rogue Status Wrangler is offline   Quote Quick Reply
Old 05-31-2010, 07:23 PM   #2
Member

Join Date: Oct 2009
Location: San Jose Calif.
Posts: 1,006
Were there supposed to be pic?

03 RUBI is offline   Quote Quick Reply
Old 05-31-2010, 07:31 PM   #3
Jeeper

solman's Avatar

Join Date: Apr 2010
Location: Southern PA
Posts: 1,667
Yes, pics would be nice.
solman is offline   Quote Quick Reply
Old 05-31-2010, 07:40 PM   #4
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
sorry guys, gettin the pics now
Rogue Status Wrangler is offline   Quote Quick Reply
Old 05-31-2010, 07:48 PM   #5
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Here is the pics and the list of parts I used.
2 - 2-1/2"x7/16" Clevis Pins
2 - Cotter Pin
4 - 7/16" Grade 5 or better washers
Torxs Bit Set (every Jeep owner should have one)
Wrench

Click image for larger version

Name:	IMG_5623.JPG
Views:	568
Size:	130.2 KB
ID:	19784

Click image for larger version

Name:	IMG_5627.JPG
Views:	309
Size:	84.9 KB
ID:	19785

Click image for larger version

Name:	IMG_5622.JPG
Views:	476
Size:	106.4 KB
ID:	19783
Rogue Status Wrangler is offline   Quote Quick Reply
Old 05-31-2010, 08:10 PM   #6
Show Me Your 8008135!

WF Supporting Member

s3nt3nc3d's Avatar

Join Date: Oct 2009
Location: Piqua, OH
Posts: 3,642
Send a message via AIM to s3nt3nc3d
Only thing with that is, I've heard some reports of snapping the clevis pins...though that doesn't seem too likely...and you need to change the pin out every few months because the head gets worn out on it and then the pin slips out. It's a decent mod for those on a budget who can't afford a nice set of discos.
__________________
"We don't build great brakes because we think you don't know how to drive, we build them for the guy on the road in front of you that doesn't." - Black Magic Brakes
s3nt3nc3d is offline   Quote Quick Reply
Old 05-31-2010, 08:31 PM   #7
Jeeper

Jma20a's Avatar

Join Date: Apr 2007
Location: Fairfield, CT
Posts: 3,046
i did this and you NEED to get the highest grade parts you can grade 5 ain't gonna last more than a few months. everything i have is grade 8, and some times you might need to add another washer to make sure that there is a snug fit, if not its just gonna get knocked around and ends up breaking.
__________________
Dear Algebra, Please stop asking us to find your X. She's never coming back and don't ask Y.
Jma20a is offline   Quote Quick Reply
Old 06-01-2010, 01:33 AM   #8
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Quote:
Originally Posted by s3nt3nc3d View Post
Only thing with that is, I've heard some reports of snapping the clevis pins...though that doesn't seem too likely...and you need to change the pin out every few months because the head gets worn out on it and then the pin slips out. It's a decent mod for those on a budget who can't afford a nice set of discos.
I agree, I plan on inspecting it/using it a lot so I'll be checking it often. Not really the money issue... I was at the hardware store anyways and thought screw it...why not try it.
Rogue Status Wrangler is offline   Quote Quick Reply
Old 06-01-2010, 01:35 AM   #9
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Quote:
Originally Posted by Jma20a View Post
i did this and you NEED to get the highest grade parts you can grade 5 ain't gonna last more than a few months. everything i have is grade 8, and some times you might need to add another washer to make sure that there is a snug fit, if not its just gonna get knocked around and ends up breaking.
Yah I bought grade 8 on all three parts. The list of parts I copy and pasted off of 4x4xplore.com. I did notice a very very slight amount of play so I'll pick up another washer tomorrow. Thanks for the advice! What I did, which I think is smart, I went and bought 2 extra pins to carry with me in my car at all times in case something snapped. Maybe overkill, but could save me in the end
Rogue Status Wrangler is offline   Quote Quick Reply
Old 06-01-2010, 12:44 PM   #10
Jeeper

RoSs's Avatar

Join Date: Apr 2010
Posts: 133
What is the point in having a quick disconnect on the sway bars???
__________________
"Hold my beer and watch this"
*Its Always Better In Texas*
RoSs is offline   Quote Quick Reply
Old 06-01-2010, 01:54 PM   #11
Moderator

WF Supporting Member
::WF Moderator::

schnutzy's Avatar

Join Date: Sep 2009
Location: ring side seats to the the country's largest circus
Posts: 28,156
Send a message via AIM to schnutzy
Quote:
Originally Posted by RoSs View Post
What is the point in having a quick disconnect on the sway bars???
while off roading, people disconnect the front sway bar so they get better flex. the quick disco's just make doing that easier.
__________________
clinging on to sanity, one motorcycle at a time.
schnutzy is offline   Quote Quick Reply
Old 06-01-2010, 02:55 PM   #12
Jeeper

Jeepzcb09's Avatar

Join Date: Jun 2009
Location: springfield,OH
Posts: 714
better flex keeps your wheels on the ground (for the most part) therefore giving you traction to get over tough obsticles, there definatly a difference when offroad connected and disconected
__________________
1998 Tj Sport: Rough Country,MetalCloak,GoodYear,Alpine,Crager,AtoZ

Check out my band:AfterTatse2010.webs
Jeepzcb09 is offline   Quote Quick Reply
Old 06-01-2010, 03:32 PM   #13
Jeeper

Jma20a's Avatar

Join Date: Apr 2007
Location: Fairfield, CT
Posts: 3,046
Quote:
Originally Posted by Rogue Status Wrangler View Post
Yah I bought grade 8 on all three parts. The list of parts I copy and pasted off of 4x4xplore.com. I did notice a very very slight amount of play so I'll pick up another washer tomorrow. Thanks for the advice! What I did, which I think is smart, I went and bought 2 extra pins to carry with me in my car at all times in case something snapped. Maybe overkill, but could save me in the end


I ordered everything from McMaster-Carr in bulk, got 12 coder pins and 12 clevis pins, get the washers from home depot.
__________________
Dear Algebra, Please stop asking us to find your X. She's never coming back and don't ask Y.
Jma20a is offline   Quote Quick Reply
Old 06-01-2010, 04:22 PM   #14
Jeeper

Join Date: Jan 2010
Location: Rock Hill, S.C.
Posts: 173
Rogue, where did you find the grade 8 parts?
__________________
/l ,[_____],
l----L- OlllllO
()_) ()_)----)_) I can fix broken, I can't fix stupid!!
oranjeep is offline   Quote Quick Reply
Old 06-01-2010, 04:40 PM   #15
Jeeper

mcgyver1467's Avatar

Join Date: Mar 2010
Location: South Carolina
Posts: 392
Quote:
Originally Posted by oranjeep View Post
Rogue, where did you find the grade 8 parts?

I second that............
mcgyver1467 is offline   Quote Quick Reply
Old 06-01-2010, 06:47 PM   #16
Show Me Your 8008135!

WF Supporting Member

s3nt3nc3d's Avatar

Join Date: Oct 2009
Location: Piqua, OH
Posts: 3,642
Send a message via AIM to s3nt3nc3d
You could prolly find grade 8 stuff at Tractor Supply... I'm not 100% sure on that, but I would think since people use some of that stuff on some pretty heavy machinery, they'd have grade 8 available for that purpose.
__________________
"We don't build great brakes because we think you don't know how to drive, we build them for the guy on the road in front of you that doesn't." - Black Magic Brakes
s3nt3nc3d is offline   Quote Quick Reply
Old 06-01-2010, 07:26 PM   #17
Member

Join Date: Oct 2009
Location: San Jose Calif.
Posts: 1,006
Those really aren't "cotter pins" per say. They're more commonly called Jesus clips in my experience. Also quick disconnects come with snap pins which are available at OSH. They're a lot stronger and are less likely to get caught on something and pulled off because the ring snaps closed over the pin.
03 RUBI is offline   Quote Quick Reply
Old 06-01-2010, 09:15 PM   #18
Show Me Your 8008135!

WF Supporting Member

s3nt3nc3d's Avatar

Join Date: Oct 2009
Location: Piqua, OH
Posts: 3,642
Send a message via AIM to s3nt3nc3d
Those are a lil different from "Jesus Clips"...when you pull those off (or if they come loose), they don't go flying...lol.

The snap pins you're talking about I think are also known as lynch pins...

__________________
"We don't build great brakes because we think you don't know how to drive, we build them for the guy on the road in front of you that doesn't." - Black Magic Brakes
s3nt3nc3d is offline   Quote Quick Reply
Old 06-02-2010, 12:07 AM   #19
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Quote:
Originally Posted by oranjeep View Post
Rogue, where did you find the grade 8 parts?
I got them at the local Ace Hardware store
Rogue Status Wrangler is offline   Quote Quick Reply
Old 06-02-2010, 11:10 AM   #20
Newb

06TJinVA's Avatar

Join Date: Apr 2010
Location: South Boston, VA
Posts: 14
Great Idea man. Whats the inside diameter on the end of the sway bar links though? So I know what diameter pin to get.
__________________
CONFIDENCE - The feeling you have before you understand the situation.
06TJinVA is offline   Quote Quick Reply
Old 06-02-2010, 09:16 PM   #21
Member

Join Date: Oct 2009
Location: San Jose Calif.
Posts: 1,006
Quote:
Originally Posted by s3nt3nc3d View Post
Those are a lil different from "Jesus Clips"...when you pull those off (or if they come loose), they don't go flying...lol.

The snap pins you're talking about I think are also known as lynch pins...

Those are the snap pins. Cotter pins are the ones that are bigger on one end and spread apart with pliers to keep them fron falling out.
03 RUBI is offline   Quote Quick Reply
Old 06-03-2010, 10:33 PM   #22
Jeeper

Join Date: May 2010
Location: Nor Cal
Posts: 23
Quote:
Originally Posted by 06TJinVA View Post
Great Idea man. Whats the inside diameter on the end of the sway bar links though? So I know what diameter pin to get.
get a 7/16th pin
Rogue Status Wrangler is offline   Quote Quick Reply
Old 06-06-2010, 08:36 AM   #23
Newb

06TJinVA's Avatar

Join Date: Apr 2010
Location: South Boston, VA
Posts: 14
Got this put on the other day and the hardest part of it was finding the part. I finally found them at Tractor Supply but they still had to order me grade 8 adjustable clevis pins. It works great thought.
__________________
CONFIDENCE - The feeling you have before you understand the situation.
06TJinVA is offline   Quote Quick Reply
Old 06-06-2010, 08:53 AM   #24
I HAVE A BELLYBUTTON!

WF Supporting Member

cavediverjc's Avatar

Join Date: Mar 2007
Location: On the grassy knoll...
Posts: 6,983
These are the pins that came with my JKS Quicker Discos. Love them. They work perfectly (the clips and the discos) and are well worth the $140 I paid for them.

These are the clips that came with my original Full Traction discos. They were alright, but were bulky and did get caught up when in tall grass. I ended up getting rid of the FT discos for JKS and haven't regretted a single minute of it......

__________________
Americans sleep safely in their beds because rough men stand ready in the night to visit violence on those who would do them harm...

Happiness is a Barrett M82A1 .50 caliber and a target at least a click out........

I come in peace. I didn't bring artillery. But I'm pleading with you with tears in my eyes, if you f**k with me, I'll kill you all.....
cavediverjc is offline   Quote Quick Reply
Old 06-06-2010, 05:56 PM   #25
Jeeper

Join Date: Jan 2010
Location: Rock Hill, S.C.
Posts: 173
[IMG][/IMG]

Here it is, my first real mod. I couldn't find a grd 8 or stainless pin after spending way too many hours, so I made these using grade 8 bolts (trimmed to size).
I'm planning a trip in Oct. and wanted to get this mod done early.
__________________
/l ,[_____],
l----L- OlllllO
()_) ()_)----)_) I can fix broken, I can't fix stupid!!
oranjeep is offline   Quote Quick Reply
Old 06-06-2010, 06:14 PM   #26
Jeeper

Join Date: Jan 2010
Location: Rock Hill, S.C.
Posts: 173
[IMG][/IMG]

OK got the image to load, harder to do than the mod.
__________________
/l ,[_____],
l----L- OlllllO
()_) ()_)----)_) I can fix broken, I can't fix stupid!!
oranjeep is offline   Quote Quick Reply
Old 11-01-2010, 05:28 PM   #27
Jeeper

Droelle's Avatar

Join Date: Jul 2010
Location: East Texas
Posts: 361
Images: 3
any one find the grade pins?
__________________
BOTTUMS UP! TOPS OFF!
Droelle is offline   Quote Quick Reply
Old 11-01-2010, 06:19 PM   #28
Jeeper

burton160w's Avatar

Join Date: Oct 2009
Location: Underneath my TJ
Posts: 1,641
Jeep Homemade Swaybar Disconnects

I actually stopped at tractor supply yesterday to get the parts, then realized how little this is worth it after you take into account the damage that 4x4xplor found after a year. The time it takes to unbolt the t-55s is nothing in comparison to the resulting crash and/or damage that can happen when this fails. All of the hardware can be found there, just it takes a minute to look (that said, I hate Tractor Supply). Those ring pins you're looking (circle red) are what are called linch pins.

Tractor Supply had everything I needed, I just personally don't want to do it, especially after considering 4x4s issue. It takes 2 minutes to unbolt the T-55 link, and even then, you can do it at home if you're driving there as long as you're not going on the highway. Save up for the JKS Quick Disco
__________________
It's got a Willy's body, a Chevy engine, Ford axles, GM transmission, and Dodge steering components... it must be a Wrangler.
burton160w is offline   Quote Quick Reply
Old 11-01-2010, 06:22 PM   #29
Jeeper

garyg's Avatar

Join Date: Oct 2010
Posts: 101
i had to get my pins out of my discos yesterday with a crowbar and a hammer! might do this mod with the new bars!
__________________
Semper Fi 2006-2010 5711 NBC
now im a pencil pusher
garyg is offline   Quote Quick Reply
Old 11-01-2010, 06:24 PM   #30
Jeeper

wolfen's Avatar

Join Date: Nov 2009
Location: Anywhere the Jeep will go
Posts: 2,328
hmmmmmm..... mental note: book mark this thread for future reference.

__________________
Ken
I am finally on board with obama's hope and change thing. I now HOPE that when its all over I have at least a little CHANGE left.
wolfen is offline   Quote Quick Reply
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the Jeep Wrangler Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
If you do not want to register, fill this field only and the name will be used as user name for your post.
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid email address for yourself.
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off


Similar Threads
Thread Thread Starter Forum Replies Last Post
JKS Sway Bar Quick Disconnects Axiom TJ General Discussion Forum 28 07-07-2013 11:23 PM
Sway bar disconnects sublimemaze TJ Tech Forum 5 09-15-2009 02:13 PM
quick disconnects arazs TJ Tech Forum 6 04-27-2009 11:44 AM
Brand New Sway bar Disconnects 4inch (MOD EDIT> Central Mass infamousbliss Classifieds Archive 5 02-07-2009 05:32 PM
Best Quick Disconnects??? jgano23 TJ General Discussion Forum 33 01-04-2009 12:41 AM


logo carid shop wrangler parts carid fender flares custom wheels store avs deflectors at carid
» Rates
Get low rates on auto insurance in Canada!

» Network Links
»Jeep Parts
» Featured Product

All times are GMT -5. The time now is 02:27 AM.



Jeep, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
