Old 06-07-2013, 11:52 AM   #31
Jeeper

Join Date: Mar 2012
Posts: 92
Quote:
Originally Posted by Jerry Bransford View Post
All automatic transmissions used in 2002 and older TJs have a vent hole opening in front that is below the top of the transmission. Don't even come close to submerging them, they are the 32RH and 30RH automatics... 3-speeds.
I have a 32rh. do I need to add a breather tube to this? is there a write-up on how to do this? '99


robhurlburt is offline   Quote Quick Reply
Old 06-07-2013, 12:13 PM   #32
Jeeper

Join Date: Mar 2013
Posts: 268
Jerry, I know where all my breather and vent tubes are except for my transmission breather. Most tubes run to the height of top of the radiator. Does the 5 speed standard, 1998 2.5 tranny have a tube or just vent on top. I will probably check after I get off work but your input is appreciated.
I fish often and am always driving deeper than I probably should. Your post got me a little worried but after 13 years of having my jeep, I ha e yet to have a tranny issue

PiePuncher is offline   Quote Quick Reply
Old 06-07-2013, 08:57 PM   #33
Jeeper

Jeeper4life's Avatar

Join Date: Dec 2012
Location: Fort Wayne, Indiana
Posts: 328
Quote:
Originally Posted by robhurlburt View Post
I have a 32rh. do I need to add a breather tube to this? is there a write-up on how to do this? '99

Hey Jerry could driving a 3 speed auto TJ through something like pictured above toss any water in your trans? Basically is it just best to keep a 3 speed auto TJ out of water as much as you can?
__________________
1997 Jeep TJ SE

2004 Jeep Liberty
Jeeper4life is online now   Quote Quick Reply
Old 06-07-2013, 10:04 PM   #34
Supporting Member

WF Supporting Member

jeepwayoflife's Avatar

Join Date: Nov 2011
Location: California/Montana
Posts: 3,169
Quote:
Originally Posted by Jeeper4life View Post

Hey Jerry could driving a 3 speed auto TJ through something like pictured above toss any water in your trans? Basically is it just best to keep a 3 speed auto TJ out of water as much as you can?
Pretty much any level of water *could* enter the transmission but with water that high, it is much more likely. The water level would be less than a foot away from the vent.
__________________
--------------------------------------------------------
jeepwayoflife is offline   Quote Quick Reply
Old 06-07-2013, 10:13 PM   #35
Jeeper

Wondertwin1's Avatar

Join Date: Sep 2011
Location: Northwest Florida
Posts: 755
Went through a hole and stalled with water almost to the top of my seat cushion. So my butt was almost getting wet. Water went through the exhaust and thankfully the cat warmed it up enough not to crack the block when it filled up the back cylinder. Pulled all the plugs and did some trail TLC. Got her home, changed the oil the next day, checked all my fluids, good to go.
__________________
I woke up this morning with good intentions, then idiots happened
Wondertwin1 is offline   Quote Quick Reply
Old 06-08-2013, 03:33 PM   #36
Jeeper

Jeeper4life's Avatar

Join Date: Dec 2012
Location: Fort Wayne, Indiana
Posts: 328
Quote:
Originally Posted by jeepwayoflife View Post
Pretty much any level of water *could* enter the transmission but with water that high, it is much more likely. The water level would be less than a foot away from the vent.
Can the torque converter splash it in though?
__________________
1997 Jeep TJ SE

2004 Jeep Liberty
Jeeper4life is online now   Quote Quick Reply
Old 06-08-2013, 03:54 PM   #37
Jeeper

wa_troop's Avatar

Join Date: Oct 2012
Location: Yelm Washington
Posts: 501
wa_troop is offline   Quote Quick Reply
Old 06-08-2013, 04:44 PM   #38
Jeeper

callbob's Avatar

Join Date: Jan 2013
Location: Cortez Colo
Posts: 636
not this deep
callbob is offline   Quote Quick Reply
Old 06-11-2013, 09:55 PM   #39
Jeeper

FloridaTJ's Avatar

Join Date: Aug 2012
Location: Florida
Posts: 115
This is why I ask, and this was just a small tropical storm, I expect more flooding down here in Florida when the hurricanes start hitting
Attached Thumbnails
Click image for larger version

Name:	image-657039629.jpg
Views:	103
Size:	193.4 KB
ID:	260470
__________________
OlllllllO
FloridaTJ is offline   Quote Quick Reply
Old 06-12-2013, 06:27 AM   #40
Jeeper

MarkGLHS's Avatar

Join Date: Aug 2012
Location: Ellington, Connecticut
Posts: 1,202
MY 2002 Dealer Brochure states they tested and approved these Jeeps for 20" of water fording. So if Jeep says 20" is okay, I have to think you could go even a few inches deeper.
__________________
2002 Wrangler Sahara, all stock, 5-speed, Dana 44, duel tan tops, 2nd owner.

2008 Hemi Grand Cherokee Limited 4X4, Quadradrive II, original owner, 22,000 miles.
MarkGLHS is offline   Quote Quick Reply
Old 06-12-2013, 07:07 AM   #41
Jeeper

kshaws21's Avatar

Join Date: Jun 2011
Location: Northeast Ga. Mountains
Posts: 1,100
Quote:
Originally Posted by FloridaTJ View Post
This is why I ask, and this was just a small tropical storm, I expect more flooding down here in Florida when the hurricanes start hitting
That's no big deal, shouldn't have any issues. The main thing when crossing water is to go slow, unless its thick soupy mud where slow is impractical.

I've seen people totally trash their engine in water that shallow just because they thought it would be cool to hit it at high speed.
kshaws21 is offline   Quote Quick Reply
Old 06-12-2013, 08:37 AM   #42
Jeeper

PStov98TJ's Avatar

Join Date: Dec 2012
Location: Long Beach, Mississippi
Posts: 2,021
Just to give a point of reference, this is where the breathers are for a jeep with the ax-5 tranny.

I didn't make this picture nor is it of my jeep. Credit goes to a member of Jeepforum
__________________
OME 2.5" coils and Nitro Shocks, Metalcloak front track bar, JKS Quick discos, 33x12.50 Goodyear MTR's w/Kevlar, 15x8 Pacer wheels, thedirtworx rear tire carrier
PStov98TJ is offline   Quote Quick Reply
Old 06-12-2013, 08:41 AM   #43
Jeeper

wa_troop's Avatar

Join Date: Oct 2012
Location: Yelm Washington
Posts: 501
Quote:
Originally Posted by PStov98TJ View Post
Just to give a point of reference, this is where the breathers are for a jeep with the ax-5 tranny.

I didn't make this picture nor is it of my jeep. Credit goes to a member of Jeepforum
There is no picture
wa_troop is offline   Quote Quick Reply
Old 06-12-2013, 08:51 AM   #44
Jeeper

PStov98TJ's Avatar

Join Date: Dec 2012
Location: Long Beach, Mississippi
Posts: 2,021
Quote:
Originally Posted by wa_troop View Post

There is no picture
My bad



The diff and t-case breather locations will all be the same (as long as you have the np231 t-case). The only thing that'll vary is the tranny breather.
__________________
OME 2.5" coils and Nitro Shocks, Metalcloak front track bar, JKS Quick discos, 33x12.50 Goodyear MTR's w/Kevlar, 15x8 Pacer wheels, thedirtworx rear tire carrier
PStov98TJ is offline   Quote Quick Reply
Old 06-12-2013, 10:46 AM   #45
Jeeper

MarkGLHS's Avatar

Join Date: Aug 2012
Location: Ellington, Connecticut
Posts: 1,202
good pix! the tranny breather being to lowest of the group appears to be about 22" off the ground, makes sense, based on Jeep's claim that the TJ is good to go thru 20" of water.
__________________
2002 Wrangler Sahara, all stock, 5-speed, Dana 44, duel tan tops, 2nd owner.

2008 Hemi Grand Cherokee Limited 4X4, Quadradrive II, original owner, 22,000 miles.
MarkGLHS is offline   Quote Quick Reply
Old 06-12-2013, 10:57 AM   #46
Jeeper

wa_troop's Avatar

Join Date: Oct 2012
Location: Yelm Washington
Posts: 501
Can u move these higher?
wa_troop is offline   Quote Quick Reply
Old 06-12-2013, 11:15 AM   #47
Jeeper

Michael Storm's Avatar

Join Date: Jun 2013
Posts: 135
I see alot of comments about if you've been really deep in water that you should be checking your engine and fluids for water etc. This concerns me seeing as how the other weekend I went through a mud "puddle" that ended up being as deep as my hood/right under. I bogged for a second, then threw the rpms and it crawled out with ease at a medium pace. I thought it was fine seeing as I made it out in a timely manner but I see comments that say I should be concerned. Is it a big deal? And how do I check for water in my axles/engine etc. Driving an 06 wrangler Btw. Stick. Thanks in advance.
Michael Storm is offline   Quote Quick Reply
Old 06-12-2013, 11:19 AM   #48
Jeeper

toolmantim's Avatar

Join Date: Apr 2013
Location: 2 miles from jeep factory
Posts: 65
if your seals and gaskets are not leaking fluid out then they are not going to let water it.

unless of course you sit submerged in water for a long period of time.
__________________
professional driver. closed course. do not attempt.
toolmantim is offline   Quote Quick Reply
Old 06-12-2013, 11:46 AM   #49
Jeeper

PStov98TJ's Avatar

Join Date: Dec 2012
Location: Long Beach, Mississippi
Posts: 2,021
Quote:
Originally Posted by wa_troop View Post
Can u move these higher?
Yes. For the diffs and t-case it's just a matter of pulling the hoses off and putting on longer ones. Depending upon what tranny you have, it could be just pulling the stock cap thing off and putting a hose in the hole or it could mean drilling into the tranny to put a fitting that a hose can attach to. For the ax-5 this is what the breather looks like: It's the little sliver cap to the left of that bolt sticking up. I took that picture so I know for 100% it is an ax-5. I saw I write up online about a guy who just pulled it off with some pliers and stuck a fitting down in it and put a hose on it. But I'm a little scared to just pull it off because that's the only write up I've seen about extending the ax-5 breather. If I can find it again I'll post it here.

Quote:
Originally Posted by toolmantim View Post
if your seals and gaskets are not leaking fluid out then they are not going to let water it. unless of course you sit submerged in water for a long period of time.
This is totally not true. Did you look at the picture I just posted? If water was above the hood, it very easily could've gotten into the front diff. And depending upon how the jeep was sitting and how much speed he had going through the hole, it could've gotten into the tranny as well. Speed is critical because too slow and the water just sits at a certain level. Too fast and you'll break stuff. But if you cruise at a good pace, the water will actually go down below the engine bay and the front of the tranny (where the breathers are located). I've been in water that momentarily cover my head lights when I dropped into a hole (it was at night so there's no doubt in my mind the water was that high). Luckily, no water got into anything but it very easily could've.

Michael Storm, I'd check your front diff fluid at the very least. You obviously got pretty lucky and didn't hydrolock your engine (I know the feeling per my story above). But make sure all breather hoses are properly attached. And if you notice one isn't attached, checks the fluids in that compartment and the firmly reattach the tube. If you have more than a 2.5-3" lift you may need to just go but tubing and extend them (this only applies to the axles unless you have a bl greater than 1.25"). I have a 2.5" OME lift and I had to reroute the rear diff breather to give it some more slack, it wasn't close to reaching. The front axle was pretty good though.
__________________
OME 2.5" coils and Nitro Shocks, Metalcloak front track bar, JKS Quick discos, 33x12.50 Goodyear MTR's w/Kevlar, 15x8 Pacer wheels, thedirtworx rear tire carrier
PStov98TJ is offline   Quote Quick Reply
Old 06-12-2013, 12:05 PM   #50
Jeeper

Michael Storm's Avatar

Join Date: Jun 2013
Posts: 135
PStov how do I go about checking that? And I definitely will extend them. I just put on half (the rear end) of a 3" lift this weekend, putting on the front Saturday since I ran out of time last visit. I'll have to try and do it then. Can I get tubing from a Napa or O' Reillys to replace it with?
Michael Storm is offline   Quote Quick Reply
Old 06-12-2013, 12:24 PM   #51
Jeeper

IslandTJ's Avatar

Join Date: Mar 2008
Location: where I wheel: N 45║ 36.663' W 123║ 20.935'
Posts: 2,665
Quote:
Originally Posted by robhurlburt View Post
I have a 32rh. do I need to add a breather tube to this? is there a write-up on how to do this? '99

Relocating vent on 32rh 3 speed auto
__________________
1998 TJ Moss Green Sahara w/ numerous scratches & dents whose playground is on a tropical island that's 33 miles long and 4-12 miles wide, in year-round 82 degree weather

Edit: "Now jeepin in Oregon"
IslandTJ is offline   Quote Quick Reply
Old 06-12-2013, 03:02 PM   #52
Jeeper

wa_troop's Avatar

Join Date: Oct 2012
Location: Yelm Washington
Posts: 501
Quote:
Originally Posted by PStov98TJ View Post
Yes. For the diffs and t-case it's just a matter of pulling the hoses off and putting on longer ones. Depending upon what tranny you have, it could be just pulling the stock cap thing off and putting a hose in the hole or it could mean drilling into the tranny to put a fitting that a hose can attach to. For the ax-5 this is what the breather looks like: It's the little sliver cap to the left of that bolt sticking up. I took that picture so I know for 100% it is an ax-5. I saw I write up online about a guy who just pulled it off with some pliers and stuck a fitting down in it and put a hose on it. But I'm a little scared to just pull it off because that's the only write up I've seen about extending the ax-5 breather. If I can find it again I'll post it here.

This is totally not true. Did you look at the picture I just posted? If water was above the hood, it very easily could've gotten into the front diff. And depending upon how the jeep was sitting and how much speed he had going through the hole, it could've gotten into the tranny as well. Speed is critical because too slow and the water just sits at a certain level. Too fast and you'll break stuff. But if you cruise at a good pace, the water will actually go down below the engine bay and the front of the tranny (where the breathers are located). I've been in water that momentarily cover my head lights when I dropped into a hole (it was at night so there's no doubt in my mind the water was that high). Luckily, no water got into anything but it very easily could've.

Michael Storm, I'd check your front diff fluid at the very least. You obviously got pretty lucky and didn't hydrolock your engine (I know the feeling per my story above). But make sure all breather hoses are properly attached. And if you notice one isn't attached, checks the fluids in that compartment and the firmly reattach the tube. If you have more than a 2.5-3" lift you may need to just go but tubing and extend them (this only applies to the axles unless you have a bl greater than 1.25"). I have a 2.5" OME lift and I had to reroute the rear diff breather to give it some more slack, it wasn't close to reaching. The front axle was pretty good though.
Could u run the hoses into a snorkel system?
wa_troop is offline   Quote Quick Reply
Old 06-12-2013, 05:31 PM   #53
Jeeper

toolmantim's Avatar

Join Date: Apr 2013
Location: 2 miles from jeep factory
Posts: 65
Quote:
Originally Posted by PStov98TJ View Post
This is totally not true.
Yes actually it is quite true.

I'm quite familiar with water and Jeeps. I first ran the water hole pictured below 9 years and 56k miles ago. Bone stock. Granted I have the OD trans that actually has a breather tube that runs up the dipstick, but I have been through my Jeep over that time with a bit of anal approach when it comes to fluids, and keeping expensive things lubricated and I can say that the single downside of my yellow submarine playing was the fan clutch. It does not like to be used as a propeller.





I'm not advising others to "do what I do and you will be fine" by any means...just saying that it is not the end of the world if ya went through a puddle.
__________________
professional driver. closed course. do not attempt.
toolmantim is offline   Quote Quick Reply
Old 06-12-2013, 06:48 PM   #54
Newb

Join Date: Mar 2013
Location: Crawfordville , Fl
Posts: 9
Yep, 32rh certain death. I don't usually go mudding, but after a day of trail riding this was the last spot we came to. My son was itching to hit some mud. Should have mad the adult decision. Almost had her rocked out till the distributor got wet. Ended up siting there for about 45 min. First replaced the starter. Then all fluids and transmission mud filter. Now I need alternator(bearings noise), transmission and a fan clutch. Yep, she'll stay out of water/mud. [IMG][/IMG]
slicxric is offline   Quote Quick Reply
Old 06-12-2013, 07:40 PM   #55
Jeeper

PStov98TJ's Avatar

Join Date: Dec 2012
Location: Long Beach, Mississippi
Posts: 2,021
Quote:
Originally Posted by wa_troop View Post

Could u run the hoses into a snorkel system?
Yes. But keep them separate (don't connect one hose to another to make one long hose) because the diffs and t-case and tranny use different fluids.

Quote:
Originally Posted by toolmantim View Post

Yes actually it is quite true.

I'm quite familiar with water and Jeeps. I first ran the water hole pictured below 9 years and 56k miles ago. Bone stock. Granted I have the OD trans that actually has a breather tube that runs up the dipstick, but I have been through my Jeep over that time with a bit of anal approach when it comes to fluids, and keeping expensive things lubricated and I can say that the single downside of my yellow submarine playing was the fan clutch. It does not like to be used as a propeller.





I'm not advising others to "do what I do and you will be fine" by any means...just saying that it is not the end of the world if ya went through a puddle.
I'm pretty familiar with water as well. It's all I've got to wheel in really; well water and mud I guess. And I wasn't trying to call you out by the way; I was just pointing out that the condition of your seals don't mean crap if the breather goes under. Sorry if I sounded aggressive. Ha
__________________
OME 2.5" coils and Nitro Shocks, Metalcloak front track bar, JKS Quick discos, 33x12.50 Goodyear MTR's w/Kevlar, 15x8 Pacer wheels, thedirtworx rear tire carrier
PStov98TJ is offline   Quote Quick Reply
Old 06-12-2013, 07:50 PM   #56
Jeeper

PStov98TJ's Avatar

Join Date: Dec 2012
Location: Long Beach, Mississippi
Posts: 2,021
Quote:
Originally Posted by Michael Storm View Post
PStov how do I go about checking that? And I definitely will extend them. I just put on half (the rear end) of a 3" lift this weekend, putting on the front Saturday since I ran out of time last visit. I'll have to try and do it then. Can I get tubing from a Napa or O' Reillys to replace it with?
Crawl under there and look for them.
Here's a D35 breather axle side:


D30 breather axle side:


D30 breather top side (small white cap thing, by the radiator):


I don't have pictures of the D35 breather top side but it's by the fuel filler neck. The np231 top side is on the firewall. As for tranny, it varies.
__________________
OME 2.5" coils and Nitro Shocks, Metalcloak front track bar, JKS Quick discos, 33x12.50 Goodyear MTR's w/Kevlar, 15x8 Pacer wheels, thedirtworx rear tire carrier
PStov98TJ is offline   Quote Quick Reply
Old 06-12-2013, 10:02 PM   #57
Jeeper

toolmantim's Avatar

Join Date: Apr 2013
Location: 2 miles from jeep factory
Posts: 65
The breather for the 42RLE (auto trans with OD on 2003-2006) is located on the dipstick tube.



The breather for the NP241 (rubicon t-case) runs out under drivers seat to about bottom of firewall behind engine block.



Notice the caps on the ends....those are important.

Truly the key to making it home is knowing how to drive through the water and having a 32rh that has been modified.
__________________
professional driver. closed course. do not attempt.
toolmantim is offline   Quote Quick Reply
Old 06-13-2013, 07:29 AM   #58
Jeeper

Join Date: Mar 2012
Posts: 92
Quote:
Originally Posted by IslandTJ View Post
hmm....so theres no way to fix the 32rh without dropping the trans? where does that breather go to? why do all the other ones have the breather out the top of the bell housing?
robhurlburt is offline   Quote Quick Reply
Old 07-02-2013, 04:39 PM   #59
Jeeper

NYJETS's Avatar

Join Date: Jun 2013
Location: FLORI-DUH
Posts: 409
Quote:
Originally Posted by RevCo666 View Post
This vid might answer some questions


That was awesome. I really liked how the BLD kicked in on the heavy snow bank
NYJETS is offline   Quote Quick Reply
Old 07-03-2013, 11:11 AM   #60
Jeeper

tbensor's Avatar

Join Date: Feb 2012
Posts: 1,145
You jeep can go all the way to the bottom of the water. Getting out is the problem. I wouldn't go deeper than the bottom frame if my vents were good.

__________________
My Toys
2003 RED Jeep Wrangler X - Can't stop adding stuff and updating.
2014 White Jeep Liberty Sport
2011 Carbon Black GMC Yukon Denali
2007 Black GMC Sierra 2500HD 4x4 Duramax/Allison
2007 Keystone Laredo 284BHS TT
tbensor is offline   Quote Quick Reply
Reply

Quick Reply
Message:
Options

Register Now

In order to be able to post messages on the Jeep Wrangler Forum forums, you must first register.
Please enter your desired user name, your email address and other required details in the form below.
User Name:
If you do not want to register, fill this field only and the name will be used as user name for your post.
Password
Please enter a password for your user account. Note that passwords are case-sensitive.
Password:
Confirm Password:
Email Address
Please enter a valid email address for yourself.
Email Address:

Log-in

Human Verification

In order to verify that you are a human and not a spam bot, please enter the answer into the following box below based on the instructions contained in the graphic.



Thread Tools

Posting Rules
You may post new threads
You may post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off



» Vendor Spotlight (Deals & More)
Jeep Parts - Jeep Wheels - Jeep Soft Tops
» Recent Threads

» Popular Tags
2.5 2014 advice audio axle bestop build bumper buying camping clutch dana 44 electrical engine exhaust fenders for sale frame hardtop hard top help advice jeep jeep tj jeep wrangler jeep yj jku leak led lift lift advice lift kit lights manual mods newbie noise oem outdoorx4 overland parts radiator rims rubicon rust sahara sale shocks soft top speakers sport springs steering stereo stock subwoofer suspension suspension lift swap tire tires tires and wheels top transfer case transmission unlimited wheels wheels and tires winch wiring wrangler
» Featured Product

All times are GMT -5. The time now is 04:25 AM.



Jeep«, Wrangler, Liberty, Wagoneer, Cherokee, and Grand Cherokee are copyrighted and trademarked to Chrysler Motors LLC.
Wranglerforum.com is not in any way associated with the Chrysler Motors LLC
