RC 2.5" lift

Was looking at the Rough country 2.5" lift and ive seen people talking about the front/rear adjustable track bars....... are they needed?

Williamc141 is offline   Quote Quick Reply
Old 08-02-2011, 10:26 PM   #2
Jeeper

Wrangler06's Avatar

Join Date: Jun 2010
Location: Roanoke Virginia
Posts: 1,643
all i needed was the rear trac bar relocation bracket, adjustable is more expensive but more worth it, your rear axle will most likely shift as mine did, my front didnt shift any at all but all jeeps are different

__________________
Impact Orange 06 Wrangler SE 2.4l 6 speed
OME and Bilsteins, 31x10.50 Kelly Safari Tsr
Magnaflow Exhaust, Rustoleum Lined Tub, Hard Top, Full Doors
Wrangler06 is offline   Quote Quick Reply
Old 08-02-2011, 10:53 PM   #3
Jeeper

Join Date: Oct 2010
Posts: 100
Yea, Ill see what happens. Still deciding which lift I should get. Like the RC 2.5" lift but still seeing what else there is out there.
Williamc141 is offline   Quote Quick Reply
Old 08-03-2011, 06:47 AM   #4
Jeeper

TXST8tj's Avatar

Join Date: Jan 2007
Location: Katy, TX
Posts: 1,779
Send a message via AIM to TXST8tj
It's a good kit for the money. It gives you a decent base to build from.
The rear tracbar bracket will get the job done just fine. An aftermarket, adjustable unit is nice, but not really necessary.
I would definitely invest in a front adjustable tracbar though; it's the best way to dial in the front end.
__________________
- Patrick
TXST8tj is offline   Quote Quick Reply
Old 08-03-2011, 12:38 PM   #5
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
Mine is adjustable in front and got the bracket in the rear. Im fine with it so far.
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 01:34 PM   #6
Jeeper

Join Date: Oct 2010
Posts: 100
Good, Will I need any special tools for the install? Ive heard about a spring compressor but is that really needed?
Williamc141 is offline   Quote Quick Reply
Old 08-03-2011, 02:15 PM   #7
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by Williamc141 View Post
Was looking at the Rough country 2.5" lift and ive seen people talking about the front/rear adjustable track bars....... are they needed?
with 2.5" of lift you do NOT, and I repeat DO NOT want an adjustable track bar unless you're prepared to adjust the bumpstop extensions accordingly. ALL aftermarket track bar create interference problems with either the differential cover or the tie-rod, usually requiring 2" or more of bumpstop extension in front. The highest clearance diff cover is the stock version, and the highest clearance track bars on the market right now are the Currie TJS/TJJ model (requires 2" front bumpstop extension to prevent hitting the stock diff cover) and the JKS new style (requires 2" front bumpstop extension to prevent hitting the tie-rod, or 1.25" bumpstop extension if used with a V8 ZJ tie-rod).

In the rear, you need to use the relocation bracket (even if you have an adjustable track bar). The stock bracket is closed on top and will cause binding with shocks longer than stock.

If you don't believe me or you think your junk is somehow different and works, I can assure you it doesn't. Read this thread: http://www.wranglerforum.com/f5/lift...ml#post1354621

Quote:
Originally Posted by Williamc141 View Post
Good, Will I need any special tools for the install? Ive heard about a spring compressor but is that really needed?
Some will tell you spring compressors aren't required, but I think they sure make life easier. I can have a springs out at least 20 minutes faster with spring compressors.
UnlimitedLJ04 is online now   Quote Quick Reply
Old 08-03-2011, 02:25 PM   #8
Jeeper

TXST8tj's Avatar

Join Date: Jan 2007
Location: Katy, TX
Posts: 1,779
Send a message via AIM to TXST8tj
It looks like the new Rough Country front adjustable track bar would clear pretty well.
Jeep XJ Shackle Relocation Kit
__________________
- Patrick
TXST8tj is offline   Quote Quick Reply
Old 08-03-2011, 02:33 PM   #9
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by TXST8tj View Post
It looks like the new Rough Country front adjustable track bar would clear pretty well.
Jeep XJ Shackle Relocation Kit
It will definitely NOT work. Anything that is straight over the diff will hit for sure.

here's that RC bar denting a stock D44:


Rusty's - same design using the same 22mm tie-rod end.


Btw, 22mm tie-rod ends are not strong enough for track bar work.

Let's see why straight bars don't work.

Thats an old style JKS vs stock. Big difference in bend.



The old style JKS needed 2" of bumpstop extension to prevent hitting the diff cover.

So JKS redesigned the track bar to kick the bend way out front....but now it hits the tie-rod instead. Requires 2" of bumpstop extension.
UnlimitedLJ04 is online now   Quote Quick Reply
Old 08-03-2011, 02:39 PM   #10
Jeeper

IndyJeepMan's Avatar

Join Date: Dec 2009
Location: Indianapolis
Posts: 3,387
No need for the front tracbar. But a rear adjustable is nice to center the axle, it wont shift very much but im sure it will some.
__________________
1980 CJ7
3.9L Cummins POWER!
Follow my build, its cool and stuff: http://www.wranglerforum.com/f118/project-shake-n-bake-a-cummins-cj-188515.html]
IndyJeepMan is offline   Quote Quick Reply
Old 08-03-2011, 08:17 PM   #11
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
O man. I just remembered. my front adj. track bar came with a bracket that went on the frame where the old one went.
And mine does not hit any thing.
I will see if i can get a pick,
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 08:33 PM   #12
Jeeper

willjeep4free's Avatar

Join Date: Jul 2011
Location: Covington, ky
Posts: 279
Ive had that same lift on my jeep for about 7 months. It's pretty good for the money you spend but it's pretty stiff. You're going to definitely feel them bumps on the road and off the road but nobody buys a jeep for luxury anyway! My alignment was off after I put it on.
willjeep4free is offline   Quote Quick Reply
Old 08-03-2011, 08:35 PM   #13
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by tailhole View Post
O man. I just remembered. my front adj. track bar came with a bracket that went on the frame where the old one went.
And mine does not hit any thing.
I will see if i can get a pick,
if it looks like this, it hits the tie-rod pretty bad. and easy to see why....



also requires a drop pitman arm...

Quote:
Originally Posted by willjeep4free View Post
Ive had that same lift on my jeep for about 7 months. It's pretty good for the money you spend but it's pretty stiff. You're going to definitely feel them bumps on the road and off the road but nobody buys a jeep for luxury anyway! My alignment was off after I put it on.
the stiffness is likely due to the RC shocks being valved poorly, and/or the improper length they're known to use...then the shocks bottom out on the street over every bump...and they don't include bumpstop extensions....remember that when wondering why the shocks are leaking in a few months.
UnlimitedLJ04 is online now   Quote Quick Reply
Old 08-03-2011, 09:05 PM   #14
Jeeper

willjeep4free's Avatar

Join Date: Jul 2011
Location: Covington, ky
Posts: 279
I'm going to have to agree with him. If you have more money get something better
willjeep4free is offline   Quote Quick Reply
Old 08-03-2011, 09:13 PM   #15
Upside-down Disorder

InvertChaos's Avatar

Join Date: Sep 2010
Location: NoVa
Posts: 7,876
I didn't need a front one but I did get the relocation bracket for the rear.
__________________
|2004 Jeep TJ "Green Machine"|4.0L 5 speed Dana44|33x12.50x15 Goodyear Duratracs|2.5" RC coils + 1.25" body lift|OME NitroSport shocks|4.56 gears|Skid Row Engine Skid|BCC Sliders|Currie AntiRock|
InvertChaos is offline   Quote Quick Reply
Old 08-03-2011, 09:25 PM   #16
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
Mine is different
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 09:26 PM   #17
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 09:33 PM   #18
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by tailhole View Post
Mine is different
that one doesn't work either.



you've got the rub mark on your diff cover...you can see it in the pic.

hitting the diff cover:


needs at least 2" front bumpstop extensions:

UnlimitedLJ04 is online now   Quote Quick Reply
Old 08-03-2011, 09:39 PM   #19
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
Only time i have noticed it hit was when i tried to take out the springs with out unbolting it. but unbolting the shocks.
I will say im not all that pleased with the kit i got. But mine rides great, really i think its a little soft.
Im probably going to be swapping out this kit. But it is ok for the price
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 09:41 PM   #20
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
Quote:
Originally Posted by UnlimitedLJ04 View Post
that one doesn't work either.



you've got the rub mark on your diff cover...you can see it in the pic.

hitting the diff cover:


needs at least 2" front bumpstop extensions:

Yea. seen that when i took that pick
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 09:51 PM   #21
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by tailhole View Post
Im probably going to be swapping out this kit.
Lots of people do. The question then remains, why waste your hard earned money on something that needs replaced soon after installation?
UnlimitedLJ04 is online now   Quote Quick Reply
Old 08-03-2011, 10:25 PM   #22
Jeeper

tailhole's Avatar

Join Date: Jul 2010
Location: oxford. ms.
Posts: 937
Live and learn, live and learn.
tailhole is offline   Quote Quick Reply
Old 08-03-2011, 10:40 PM   #23
"Seamed Like a Good Idea

WF Supporting Member

TJWenatchee's Avatar

Join Date: Jun 2011
Location: Near Wenatchee, WA
Posts: 1,200
Images: 29
Have relocation bracket for rear on my Rancho 2.75" Lift. Stock up front works just fine.
__________________
See my TJ Build Page on Facebook
TJWenatchee is offline   Quote Quick Reply
Old 08-04-2011, 01:51 PM   #24
Jeeper

Join Date: Oct 2010
Posts: 100
I will have around 450-500 for the lift, 2"-3" is what im looking for.. If you got something good for that price range link me to it!
Williamc141 is offline   Quote Quick Reply
Old 08-04-2011, 11:10 PM   #25
Jeeper

Join Date: Oct 2010
Posts: 100
someones gotta have their personal opinion on a good lift.
Williamc141 is offline   Quote Quick Reply
Old 08-05-2011, 07:36 AM   #26
Jeeper

UnlimitedLJ04's Avatar

Join Date: Aug 2010
Posts: 6,875
Quote:
Originally Posted by Williamc141 View Post
someones gotta have their personal opinion on a good lift.
Look at RCD's 3", OME 2.5" or the Savvy/Currie 3".

UnlimitedLJ04 is online now   Quote Quick Reply
