snittybuilt rear bumper rattle trap

I didn't install and I'm really tired of this thing rattling all the time. I put a plastic piece in the "square" where it latches. Didn't help. It's that stupid golden latch. It has room inside its housing to move aroundso if I hit ANY bump

Click image for larger version

Name:	ForumRunner_20120522_233807.jpg
Views:	101
Size:	66.6 KB
ID:	125411



Click image for larger version

Name:	ForumRunner_20120522_233839.jpg
Views:	99
Size:	75.8 KB
ID:	125412

tcrawford is offline   Quote Quick Reply
Old 05-22-2012, 11:44 PM   #2
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
Quote:
Originally Posted by tcrawford
I didn't install and I'm really tired of this thing rattling all the time. I put a plastic piece in the "square" where it latches. Didn't help. It's that stupid golden latch. It has room inside its housing to move aroundso if I hit ANY bump
Oops got an itchy trigger finger hit send to early...anyway if I hit any bump it rattles and on these off road trails that are inner city Houston streets there are plenty of bumps. Has anybody dealt with this/ have any ideas. I'm going crazy. And I don't need the don't by smittybuilt products response. Any kind of help is appreciated.

tcrawford is offline   Quote Quick Reply
Old 05-23-2012, 12:04 AM   #3
Jeeper

WF Supporting Member

O_M_Jeep's Avatar

Join Date: Aug 2011
Location: South Central Wyoming
Posts: 1,129
I'm guessing you made sure the hinge side is good and tight and greased?

If the rattle is at the locking pin, you might try this, in the area the pin seats in to, try filling it with silicone, let it dry and cure fully and then carefully drill a hole for the pin being careful not to dislodge the silicone, or, you could, if you don't mind it looking oddly, try using a thick almost a weather stripping tape on the pin itself.

The tape would be a temp fix compared to the silicone, but faster / easier.

Hope that gives you at least a starting point for ideas. Good luck and let us know how you fix it and don't forget the pics.
__________________
There are a million ways to build a Jeep, pick one and do it - you bought a canvas, not a painting!

Click here to support Wranglerforum
Or else the teddy bear gets it
O_M_Jeep is offline   Quote Quick Reply
Old 05-23-2012, 04:08 AM   #4
Jeeper

WF Supporting Member

coley's Avatar

Join Date: Aug 2011
Location: Hopatcong, NJ
Posts: 338
Images: 5
I bolted an angle where the wedge was on the tire carrier, welded, drilled and tapped a block on the bumper. Bought a stainless 5/16 x 18 hand knob….. and no more rattle.

coley is offline   Quote Quick Reply
Old 05-23-2012, 04:14 AM   #5
Jeeper

blkrubi88's Avatar

Join Date: Nov 2009
Location: Clayton NC
Posts: 24,099
Mine developed a rattle after years of no rattle, so I bought and installed this, no rattles at all now and extra security on keeping it closed.










__________________
I can only please one person a day and today is not your day and tomorrow is not looking good either!



CHRIS
blkrubi88 is offline   Quote Quick Reply
Old 05-23-2012, 07:06 AM   #6
Newb

Join Date: Feb 2012
Location: Groton, Ct
Posts: 6
Thanks for the ideas guys! This has been driving my husband and I nuts as well! We were going to try plasti-dip on the pin but I love the knob idea. Where did you get it at? Home Depot or something?
daddyslilgirl is offline   Quote Quick Reply
Old 05-23-2012, 07:41 AM   #7
Jeeper

WF Supporting Member

coley's Avatar

Join Date: Aug 2011
Location: Hopatcong, NJ
Posts: 338
Images: 5
I Like that latch. Very nice.

I bought the knob at McMaster-Carr Supply Item# 4384K51

McMaster-Carr
coley is offline   Quote Quick Reply
Old 05-23-2012, 08:46 AM   #8
Jeeper

blkrubi88's Avatar

Join Date: Nov 2009
Location: Clayton NC
Posts: 24,099
Quote:
Originally Posted by coley View Post
I Like that latch. Very nice.

I bought the knob at McMaster-Carr Supply Item# 4384K51

McMaster-Carr
Thanks, got it off Amazon for $40.
__________________
I can only please one person a day and today is not your day and tomorrow is not looking good either!



CHRIS
blkrubi88 is offline   Quote Quick Reply
Old 05-23-2012, 10:14 AM   #9
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
Quote:
Originally Posted by blkrubi88 View Post
Mine developed a rattle after years of no rattle, so I bought and installed this, no rattles at all now and extra security on keeping it closed.









Maybe im missing something but how would that latch keep the existing latch from rattling around?
tcrawford is offline   Quote Quick Reply
Old 05-23-2012, 11:01 AM   #10
Jeeper

blkrubi88's Avatar

Join Date: Nov 2009
Location: Clayton NC
Posts: 24,099
Quote:
Originally Posted by tcrawford View Post
Maybe im missing something but how would that latch keep the existing latch from rattling around?
Without that latch, the swing as enough movement for the factory latch to vibrate against the square hole, which is were the rattle comes from. The latch I installed stops any movement in the swing, which equals no rattles.
__________________
I can only please one person a day and today is not your day and tomorrow is not looking good either!



CHRIS
blkrubi88 is offline   Quote Quick Reply
Old 05-23-2012, 11:18 AM   #11
Jeeper

WF Supporting Member

coley's Avatar

Join Date: Aug 2011
Location: Hopatcong, NJ
Posts: 338
Images: 5
Quote:
Originally Posted by blkrubi88 View Post
Without that latch, the swing as enough movement for the factory latch to vibrate against the square hole, which is were the rattle comes from. The latch I installed stops any movement in the swing, which equals no rattles.
Same here. My latch wasn't making the noise. It was the carrier against the bumper.

Your experience may differ.
coley is offline   Quote Quick Reply
Old 05-25-2012, 08:43 PM   #12
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
I called smittybilt and they say we recommend putting silicone onto the square while the latch is in there. How would YOU(yes, any of you) go about doing that?
tcrawford is offline   Quote Quick Reply
Old 05-25-2012, 08:52 PM   #13
Jeeper

srad600's Avatar

Join Date: Apr 2011
Location: Tabernacle, NJ
Posts: 1,683
I zip tied a piece of foam on the metal part of the bumper and where the metal part of the tire carrier contact is. Black zip tie, grey foam, no rattle. May sound ghetto but its unseen and free.
__________________
The Budget Brawler. AKA Berta
97 sport 4.0 5 spd
6" Long arm 35" MTRs
HP30-Eaton E locker D44-Detroit locker-4.88 Ten Factory Chromo shafts.
KC/Hella, Engo 12k, LED rock lights, "train" horns, Home made-Hand Throttle, OBA, Etc etc.
srad600 is offline   Quote Quick Reply
Old 05-25-2012, 09:31 PM   #14
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
Do you have a picture. I'm not exactly sure where you are talking about. I like easy and cheap.
tcrawford is offline   Quote Quick Reply
Old 05-25-2012, 09:35 PM   #15
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
Do you mean where that plastic bump stop type thing is? How thick is the foam?
tcrawford is offline   Quote Quick Reply
Old 05-25-2012, 10:03 PM   #16
Jeeper

Pipp88's Avatar

Join Date: Sep 2010
Location: St.Amant, LA
Posts: 110
What I did was I took the pin that is used to pick up the latch off. That pin if I rember is a 8mm thread I got a 8mm bolt nut and washer ran the nut all the way up the threads and welded it to the nut. That gave it a shoulder then I used another bolt to make a T handle. So when you tighten the bolt it pulls the latching pin and it stop all the noise. Sorry the pic is not that good buts it's all I have.
Attached Thumbnails
Click image for larger version

Name:	image-1905069368.jpg
Views:	50
Size:	109.9 KB
ID:	126172
Pipp88 is offline   Quote Quick Reply
Old 05-26-2012, 10:36 PM   #17
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
Thanks for all the suggestions. Last night I took the easy out. I just took the latch out and sprayed it down with bed liner. Actually seems to have gotten rid of most of the rattle. Also added washers inbetween the plastic wedge piece next the latch so the the carrier is tight with bumper.
tcrawford is offline   Quote Quick Reply
Old 05-31-2012, 12:35 PM   #18
Jeeper

tcrawford's Avatar

Join Date: May 2012
Location: Houston, TX
Posts: 46
I spoke to soon. Will be looking for new solutions this weekend after my CFA exam.
