Old 03-04-2012, 12:22 PM   #1
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
V8 Motor swap/ 89 YJ build

Well im gonna start a new thread specific to the motor and future plans. I have a lot of pics. This is going to be a 6.0 vortec motor/ Gen 3 ls motor. A turbo 350 transmission and tcase is still a little bit unsure but hoping to go atlas 2.





one perch cleaned

2 perchs cut and cleaned ready for new motor mounts

jungle gym of steering- need to remove steering box and move it foward, have sway bar and trac bar out

89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 12:38 PM   #2
Jeeper

Join Date: Oct 2011
Location: wasilla ak
Posts: 98
This is great. Just curious as to why you are going to use the turbo 350 tranny?

shayno is offline   Quote Quick Reply
Old 03-04-2012, 12:55 PM   #3
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
The turbo 350 is very short and i wanted to have as long a drive shaft as possible. THey are cheap and can easily be built to handle the power. For budge reasons i am using a stock one for the time being and will keep it till i blow it up.
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 01:16 PM   #4
Jeeper

yjJEEPyj's Avatar

Join Date: Sep 2011
Location: Davenport Iowa
Posts: 1,023
Looking forward to this build! Is your engine going to be stock when you buy it and build it up yourself? How much do they run?? $?? (your silver axles look nice
__________________
Check out my build thread here!
http://www.wranglerforum.com/f8/94-yj-build-120345.html
yjJEEPyj is offline   Quote Quick Reply
Old 03-04-2012, 01:24 PM   #5
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
I have the 6.0 vortec which i payed $800 for it. I ordered headers for $333, the radiator and fan are going somewhere around $700 which i cant affoard right now. trans was $250, Stand alone wiring is $1400, transfercase is undecided but leaning towards atlas 2, motor mounts was steal i had laying around, a lot of grinding wheels and cutting wheels, flux, aargon, fuel pump, and just random odds and ends they ill have to buy and cant think of. And thanks for compliment on axles. I got bored of black sooo i sanded them down and turned them silver.
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 01:40 PM   #6
2xs
Cali Smog Nazi.

WF Supporting Member

2xs's Avatar

Join Date: Jun 2011
Location: Santa Rosa, Ca.
Posts: 2,647
Images: 3
Wow, nice bend in your drag Link...

and more pics please...
__________________
'93 Black YJ, 4.0L AX15 - UNDER CONSTRUCTION!
http://www.wranglerforum.com/f330/2x...ad-490865.html
'04 SV1000s:
http://www.svrider.com/forum/showthread.php?t=280873
Old Jeep that was totaled (and SOLD!):
http://www.wranglerforum.com/f330/2x...ad-101879.html
2xs is offline   Quote Quick Reply
Old 03-04-2012, 02:10 PM   #7
Jeeper

944.0's Avatar

Join Date: Dec 2011
Posts: 65
Great thread. I'm def following this one.
944.0 is offline   Quote Quick Reply
Old 03-04-2012, 05:04 PM   #8
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
thats the stock drag link for the f250 super duty, not bent from jumping or anything. Ok well i got the perchs measured, i tacked them, test fit the motor and finished the welds all the way around. here is some pics.
tacked on

Test fit

fulled welded
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 05:06 PM   #9
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
if you want to see the axle swap go to http://www.wranglerforum.com/f8/f350...p-95020-6.html i have a bunch of threads for just about everything ive done. im open to any questions you may have.
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 05:19 PM   #10
Sponsoring Vendor

Ibuildembig's Avatar

Join Date: Aug 2010
Location: Fruitland, Missouri
Posts: 8,410
Quote:
Originally Posted by 89JEEPYJ View Post
I have the 6.0 vortec which i payed $800 for it. I ordered headers for $333, the radiator and fan are going somewhere around $700 which i cant affoard right now. trans was $250, Stand alone wiring is $1400, transfercase is undecided but leaning towards atlas 2, motor mounts was steal i had laying around, a lot of grinding wheels and cutting wheels, flux, aargon, fuel pump, and just random odds and ends they ill have to buy and cant think of. And thanks for compliment on axles. I got bored of black sooo i sanded them down and turned them silver.
First of all I can't believe you bought motor mounts instead of make um

Secondly, just get a radiator from Champion and a Mark 8 fan....lots cheaper than 700 bucks
Ibuildembig is online now   Quote Quick Reply
Old 03-04-2012, 05:28 PM   #11
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
i was going to get the radiator from novak and the matching fan. you have a link for either of those things. The mounts were pretty cheap as well. I have very little time so it was nice to have motor done in less then a hour. its back out sooo i can get out the 3 manifold bolts that broke inside the block. I am going to use the cutting torch method
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 06:09 PM   #12
Jeeper

brent in az's Avatar

Join Date: Feb 2010
Location: Verde Valley, AZ
Posts: 421
I love ambitious projects. If you bought a rad from Novak (the best most educational jeep site there is) than money is no object to you. My comments were going to be in the vein if money IS an object you could get away with dumping the Atlas TC and newer trans for a trustworthy Dana and a T-18...all, as you know, adaptable via Novak, to your vortec. I think the Atlas and over-digital trans are far-overrated compared to the old school...

What you need to do when you're done is post a .wmv file of how it SOUNDS cause that's going to be cool.
brent in az is offline   Quote Quick Reply
Old 03-04-2012, 06:14 PM   #13
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
haha money is deff an issue for me. My problem is im tired of breaking shit over and over again. im saving my ass off and basically stripping my jeep of any none essential after market parts so i can affoard everything. the motor and stuff is a quick swap but the transfercase and the motor wirring harness will not be affoardable for a few months
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 07:55 PM   #14
Jeeper

brent in az's Avatar

Join Date: Feb 2010
Location: Verde Valley, AZ
Posts: 421
Quote:
Originally Posted by 89JEEPYJ View Post
haha money is deff an issue for me. My problem is im tired of breaking shit over and over again. im saving my ass off and basically stripping my jeep of any none essential after market parts so i can affoard everything. the motor and stuff is a quick swap but the transfercase and the motor wirring harness will not be affoardable for a few months
Meant no disrespect my brother, I'm sick of breaking stuff too. If I saw a gm vortec for 800 bones I would go to town as well. Novaks got nice rads by the way. When I installed a V8 into another jeep the BIGGEST problem was configuring the cooling system because your jeep is going to get really hot. A steel 4-core worked for me but aluminum is the way to go. You might consider trans/oil coolers too. It's strange you say the wiring harness is $$$$---must be state of the art. Last one I installed was $150 but these were analog days---keep this thread alive, it's an exciting project.
brent in az is offline   Quote Quick Reply
Old 03-04-2012, 08:02 PM   #15
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
I do have the complete stock harness with computer and everything and technically i could have it reprogrammed for about 150, my problem is i dont want to go through the ton of wires and figure out gauages, ignition, power and just all that stuff. i just want to do it right for once, i half assed things way too many times
89JEEPYJ is offline   Quote Quick Reply
Old 03-04-2012, 08:28 PM   #16
Sponsoring Vendor

Ibuildembig's Avatar

Join Date: Aug 2010
Location: Fruitland, Missouri
Posts: 8,410
Here ya go...I ran um before on my 347 and I bought on for my new stroker motor as well. Let me know when your ready for a fan, I can hook you up.

Jeep Wrangler (87-06)
Ibuildembig is online now   Quote Quick Reply
Old 03-04-2012, 08:37 PM   #17
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
oooo thats a pretty cool link that ill deff compare prices to. Haha i have no idea which one to get, and i noticed that none of them have the line for the engine cooler which my motor needs, but isnts completely needed
89JEEPYJ is offline   Quote Quick Reply
Old 03-05-2012, 09:47 AM   #18
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
Am i able to put the motor in without the headers on and put headers on after. or am i going to have to put it all in at once?
89JEEPYJ is offline   Quote Quick Reply
Old 03-05-2012, 03:59 PM   #19
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
So i have my special flex plate ordered which allows the turbo 350 torque converter to bolt up. The headers are ordered as well. All these parts will be here thursday. Cleaned the motor a little bit today and will probably paint it tomorrow. I have 3 broken manifold bolts that are broken inside the block and i broke an extractor inside of 1 soo i dont know where im going to brg it to get them out for a reasonable price.
89JEEPYJ is offline   Quote Quick Reply
Old 03-05-2012, 05:45 PM   #20
Jeeper

SandyMushYJ's Avatar

Join Date: Nov 2010
Location: Asheville, NC
Posts: 357
Quote:
Originally Posted by 89JEEPYJ View Post
So i have my special flex plate ordered which allows the turbo 350 torque converter to bolt up. The headers are ordered as well. All these parts will be here thursday. Cleaned the motor a little bit today and will probably paint it tomorrow. I have 3 broken manifold bolts that are broken inside the block and i broke an extractor inside of 1 soo i dont know where im going to brg it to get them out for a reasonable price.
Some of the Meinekes up nawth can blast them out with a cutting torch.
__________________
'95 YJ 2.5L, 5-sp, 2.5" lift, 31" Pro Comp MT's

'62 Willys pickup Super Hurricane L6
Original, disassembled and in slow progress.
SandyMushYJ is offline   Quote Quick Reply
Old 03-05-2012, 07:53 PM   #21
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
Since my parts dont come in till thursday i started cutting all the perchs out from under the hood, sway bars, trac bars, steering box brace, the 3 inch tube cross brace and anything else i could find to cut off. Im stretching the steering box. I havent decided if i want to cap off the hole from the tube or if i want to completey remove that part and buy some 4x2 tubing and shift the where the steering box is now foward as far as needed and then use the tubing to hold it in place. Here are some pics




and i have some more pics that havent uploaded to photo bucket through my phone yet
89JEEPYJ is offline   Quote Quick Reply
Old 03-06-2012, 08:30 PM   #22
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
While waiting for my parts to come in i started taking care of the steering. I need to stretch the steering box foward soo i did the chassie work, heres the pics.

New section made with steering box in proper place.

Put the double sheer high steerarms in so i could find proper place for my steering box.

Cleaning all the surfaces

I ended up running out of welding gas as well as running out of all my grinding wheels. Going to weld the newly made things in tomorrow morning
89JEEPYJ is offline   Quote Quick Reply
Old 03-06-2012, 10:38 PM   #23
Jeeper

kmanator's Avatar

Join Date: Nov 2011
Posts: 287
Wowzers!...I think I would've made a custom drop pitman arm or tried a Astro van steering box before got the torch out...kman
Astro van steering box for stretching...
kmanator is offline   Quote Quick Reply
Old 03-06-2012, 10:41 PM   #24
Sponsoring Vendor

Ibuildembig's Avatar

Join Date: Aug 2010
Location: Fruitland, Missouri
Posts: 8,410
I dunno if I would have cut the crossmember out, but its not my rig.
Ibuildembig is online now   Quote Quick Reply
Old 03-06-2012, 11:55 PM   #25
Jeeper

Join Date: Dec 2010
Posts: 28
Y not Carb the 6.0 Med makes a box to run it . Is it truck or escapade motor . Over 500 horse with cam and intake with a carb
jasontibbs is offline   Quote Quick Reply
Old 03-07-2012, 12:10 AM   #26
Jeeper

AZ WRANGLER's Avatar

Join Date: Apr 2010
Location: Phx, AZ
Posts: 266
Looking good Jeepy!!!

I just bought my radiator from Novak. Definately the best one on the market. The mounting system is nice too.I have some pics on my build thread. I bought their motor mounts also.

We will have to keep in touch on our builds. I'm a little further than you, but I have a feeling you will be catching up quick! I'm not looking forward to the wiring...

Here is my build, stay in touch!

http://www.wranglerforum.com/f8/95-y...-141156-2.html
AZ WRANGLER is offline   Quote Quick Reply
Old 03-07-2012, 07:59 PM   #27
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
well i got a lot done today, the steering box is bolted in place and the chassie replacement is welded into place. I connected the other high steer arm and i cut them to size and welded the hiem joints in. If you look at the pics that bar going across is welded in which should act as a cross brace. On top of that i plan to use the extra tubing from the steering to add another cross brace which i will install at the end when everytjhing is in to ensure it doesnt effect anything else. I plan to weld in the trac bar mounts in tonight as well. I was able to extra the rest of the broken bolts from the block today by using a weld a bolt to it method. Here is some pics. And the main reason i am doing this swap is the fact that i was tired of the truck running differently every day and constantly having to adjust it. HP is nice but its not my main concern, I wont to be able to run at any angle and be able to continue running with out any worries of bogging down. It is multiport fuel injection so it will also be very efficient. if i was going to use a carb i would of just kept my stock motor.
2 pieces welded together and grinded clean, almost perfectly smooth and cant see where the parts join

mocked up and tacked in place.

Had to cut the top of the steering box which is out of a durango to clear the cross brace.

passenger side high steer on

steering box in its new home

the jungle gym is begining to grow. the angle isnt perfectly perpindicular but its 100xs better then it was. it could of used about another inch foward but i was right up against the front sleeve for the steering box. But there is no binding or anything
89JEEPYJ is offline   Quote Quick Reply
Old 03-07-2012, 08:05 PM   #28
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
Im going 10hours round trip tomorrow to buy my competition rear fenders for when i stretch the rear for a nice big driveshaft. the motor and tranny should be in the truck by friday for good. I leave for college again on Sunday so there will be a big gap in my build accomplishment. when i go away the saving will begin to buy everything else. All the fabrication and hard work is done until i begin the suspension built
89JEEPYJ is offline   Quote Quick Reply
Old 03-08-2012, 11:29 PM   #29
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
didnt acomplish much today. Spent the day driving to get bolts for the steering, trac bar and transmisssion and driving to buy my comp rear fenders
89JEEPYJ is offline   Quote Quick Reply
Old 03-09-2012, 07:33 PM   #30
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
Motor and tranny all cleaned up

Dropping both things in together

waiting for pic of motor in to upload to photo bucket

89JEEPYJ is offline   Quote Quick Reply
