any thoughts as to wht this might be??

ive been trying to figure this out.. maybe a trailer brake controller (noticing the two screws... BUT theres no hitch on it... i really have no clue as these are 1/2 doors.... the yellow/white has the correct ends to the blue... i can only see these on the driver door...
Attached Thumbnails
Click image for larger version

Name:	IMG_20130622_115007_175.jpg
Views:	67
Size:	164.9 KB
ID:	267383   Click image for larger version

Name:	IMG_20130622_115017_502.jpg
Views:	72
Size:	185.8 KB
ID:	267384


twinge is offline   Quote Quick Reply
Old 07-01-2013, 12:35 AM   #2
Jeeper

Slater451's Avatar

Join Date: Oct 2012
Location: Syracuse NY
Posts: 849
What do the wires go to in the door? Have you taken the interior panel off to see where the go?

Slater451 is offline   Quote Quick Reply
Old 07-01-2013, 01:16 AM   #3
Jeeper

Join Date: Jun 2013
Location: Saginaw, MI
Posts: 157
Send a message via Yahoo to twinge Send a message via Skype™ to twinge
Quote:
Originally Posted by Slater451 View Post
What do the wires go to in the door? Have you taken the interior panel off to see where the go?
ive had the panel off in the interior but i cannot find where they go to, as for the door, idk because theres nothing out there tht would make any sense.... theres nothing electrical in the door
twinge is offline   Quote Quick Reply
Old 07-01-2013, 08:31 AM   #4
Jeeper

terry44's Avatar

Join Date: Jul 2013
Posts: 20
Could it be for the switch that tell you your door is still open.
terry44 is offline   Quote Quick Reply
Old 07-01-2013, 08:31 AM   #5
Jeeper

Slater451's Avatar

Join Date: Oct 2012
Location: Syracuse NY
Posts: 849
Weird .... Can you post pics of the Inside and the outside of the door?
Slater451 is offline   Quote Quick Reply
Old 07-01-2013, 08:51 AM   #6
Jeeper

Join Date: Jun 2013
Location: Saginaw, MI
Posts: 157
Send a message via Yahoo to twinge Send a message via Skype™ to twinge
Quote:
Originally Posted by terry44 View Post
Could it be for the switch that tell you your door is still open.
the pin is in the tub that indicates door open, thats what i thought initially... soo i plugged it in anyway with the jeep both on and off. no door lights (only when i turn the key off)

i will work on getting the door off here in a few, cause im curious as hell
twinge is offline   Quote Quick Reply
Old 07-12-2013, 04:05 PM   #7
Jeeper

Join Date: Jun 2013
Location: Saginaw, MI
Posts: 157
Send a message via Yahoo to twinge Send a message via Skype™ to twinge
Finally got around to pulling the door panel... This is what i found.

It is an actuator for the lock... I can't find the brain for it, and there's also no wire going to the passenger door...
__________________
2005 Impact Orange TJ 4.0, 6spd - Hella 500ff's, MB Chaos 5's - gone

2009 Black Sahara JKU - Hella 500FF's on the pillars.
twinge is offline   Quote Quick Reply
Old 07-13-2013, 06:38 PM   #8
Jeeper

lensam's Avatar

Join Date: Dec 2011
Location: Bridgeport CT
Posts: 267
could they be speaker wires for the doors???
__________________
2006 Rubicon Soft Top



It Looks Good From My House !!!
lensam is offline   Quote Quick Reply
Old 07-14-2013, 12:38 AM   #9
Jeeper

OhSixTJ's Avatar

Join Date: Mar 2013
Posts: 1,108
Quote:
Originally Posted by twinge View Post
Finally got around to pulling the door panel... This is what i found.

It is an actuator for the lock... I can't find the brain for it, and there's also no wire going to the passenger door...
Maybe the PO was single and only needed to unlock one door.
OhSixTJ is offline   Quote Quick Reply
Old 07-14-2013, 12:44 AM   #10
Jeeper

HillbillyJeeper's Avatar

Join Date: Jun 2011
Location: Nun yo gyatdamn biniz!
Posts: 1,043
weird. No lock buttons on door?
__________________
OUTHOUSE OFFROAD CLUB!!! We Do Shit!!


That was Purdy as hell right there!!!!

Uh.... dad... Uncle Jessie is crazy! Sooo cool though!
HillbillyJeeper is offline   Quote Quick Reply
Old 07-14-2013, 12:48 AM   #11
Jeeper

Join Date: Jun 2013
Location: Saginaw, MI
Posts: 157
Send a message via Yahoo to twinge Send a message via Skype™ to twinge
Quote:
Originally Posted by HillbillyJeeper View Post
weird. No lock buttons on door?
They are the 1/2 doors, they have the manual locks
__________________
2005 Impact Orange TJ 4.0, 6spd - Hella 500ff's, MB Chaos 5's - gone

2009 Black Sahara JKU - Hella 500FF's on the pillars.
twinge is offline   Quote Quick Reply
Old 08-03-2013, 02:12 PM   #12
Jeeper

Join Date: Jun 2013
Location: Saginaw, MI
Posts: 157
Send a message via Yahoo to twinge Send a message via Skype™ to twinge
Finished my investigation today... P.o. Had some form of keyless/alarm... Damn i threw out my old viper unit would love to have seen if it worked.....
__________________
2005 Impact Orange TJ 4.0, 6spd - Hella 500ff's, MB Chaos 5's - gone

2009 Black Sahara JKU - Hella 500FF's on the pillars.
twinge is offline   Quote Quick Reply
Old 08-08-2013, 08:48 PM   #13
Newb

Join Date: Jul 2013
Posts: 9
Ok so i know that you finished your investigation and I'm sure you figured out that the wires coming out of the door are from the actuator that was installed with the keyless system. Its the piece with the black rubber grommet attached to the inside of the door via the silver screws in the pic. Sorry the response is late but I just saw the thread.
