New to HAM and need antenna advice

Hey guys. I got my HAM license (KK6CXJ) and I want a 2 meter radio in my JK. I've ordered a Kenwood TM-281A 2M radio. I have the radio mounting all figured out, but need some help with the antenna. I want to be able to pull my Jeep into the garage. My brother (a general license) said I shouldn't go shorter than a 1/2 wave antenna, but it seems they're all over 48" long (too tall). I think 36" is about as tall as I can go and fit it in the door. I could use some advice. Pictures of anyone's setup that would fit my needs would be great too.

__________________
2013 Wrangler 2D, 3.6L, Automatic, 3.73 Gears, Limited slip in the rear, Teraflex 2" lift, 285/75/16 tires, LOD bumper & 8K winch, 2M Ham radio.

People sleep peaceably in their beds at night only because rough men stand ready to do violence on their behalf- George Orwell
Joe Dirt is offline   Quote Quick Reply
Old 12-03-2013, 12:45 AM   #2
Jeeper

Joe Dirt's Avatar

Join Date: Mar 2007
Location: Murrieta, CA
Posts: 1,075
I'm looking at this mounting location.
Attached Thumbnails
Click image for larger version

Name:	Jeep-Photo[1].jpg
Views:	62
Size:	163.5 KB
ID:	561682

__________________
2013 Wrangler 2D, 3.6L, Automatic, 3.73 Gears, Limited slip in the rear, Teraflex 2" lift, 285/75/16 tires, LOD bumper & 8K winch, 2M Ham radio.

People sleep peaceably in their beds at night only because rough men stand ready to do violence on their behalf- George Orwell
Joe Dirt is offline   Quote Quick Reply
Old 12-03-2013, 10:19 AM   #3
Jeeper

OhSixTJ's Avatar

Join Date: Mar 2013
Posts: 1,092
Wire antennas are flexible. My 1/2 wave hits the carport everytime.
OhSixTJ is offline   Quote Quick Reply
Old 12-03-2013, 10:40 AM   #4
Jeeper

sparky's Avatar

Join Date: Oct 2009
Location: Phila
Posts: 1,786
You don't need a 1/2 wave antenna, a 1/4 wave antenna will work fine. A lot of them are only 19". Take a look at Comet and Diamond brands. While I try and stay away from front mount antenna, these could go off the side of your hood or on the front fenders (TJ or YJ) and work pretty well. Mounted on your spare tire bracket is possible with some reduced performance.

Not the only place to buy, but here is a selection with dimensions listed; Amateur Mobile Antennas
sparky is offline   Quote Quick Reply
Old 12-03-2013, 10:51 AM   #5
KMG 365

WF Supporting Member

Sccafire's Avatar

Join Date: Oct 2011
Location: 92 miles from the Rubicon Trail
Posts: 715
I have a Diamond Antenna and it folds over. Just stop before entering garage and fold it over. You will find that most will do that.
__________________
Scott
Sccafire is offline   Quote Quick Reply
Old 12-03-2013, 01:41 PM   #6
2.5L SYMPATHIZER

WF Supporting Member

W5KVV's Avatar

Join Date: Oct 2013
Location: S.E. Oklahoma
Posts: 820
The 281 is a good rig. I had one in the shack before I upgraded to a dual band.

I haved used Larsen NMO atennnas for years. They can take a beating. I run the NMO 2/70B, it's a dual band antenna for 2m/70cm. It's about 33" tall. http://www.universal-radio.com/catal...m/larsenm.html

If you run the dual band antenna now, you can upgrade your rig to a dual band in the future. A simple fender bracket would work for what you're after.
__________________
1995 Rio Grande - 2.5 - AX5 - 160k -
4"RC - 1/2"booms - 33's -




W5KVV is offline   Quote Quick Reply
Old 12-06-2013, 08:47 PM   #7
Jeeper

Joe Dirt's Avatar

Join Date: Mar 2007
Location: Murrieta, CA
Posts: 1,075
What is the difference/advantage of a 1/2 wave vs a 1/4 wave
__________________
2013 Wrangler 2D, 3.6L, Automatic, 3.73 Gears, Limited slip in the rear, Teraflex 2" lift, 285/75/16 tires, LOD bumper & 8K winch, 2M Ham radio.

People sleep peaceably in their beds at night only because rough men stand ready to do violence on their behalf- George Orwell
Joe Dirt is offline   Quote Quick Reply
Old 12-07-2013, 01:39 PM   #8
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 31,161
Images: 2
In theory 1/2 wave is very slightly better than a 1/4 wave is at communicating over long distances but at the VHF frequencies 2m is at, both are limited to line-of-sight distances anyway. And a 5/8 is better yet. But in real-world 2m use, there isn't enough difference for most 2m radio users where I'd worry about it.

But since most communications via 2m is done via repeaters where maximum range isn't usually an issue, a 1/4 wave is fine. I used a tiny mag-mount dual-band antenna for my 2m radio for years & it worked fine since 99% of my ham communications takes place over repeaters. I only went to a longer 5/8 wave Hustler SF-2 antenna for simplex use when I started volunteering for the King of the Hammers event. They had me located at remote check points where there were no repeaters and best possible simplex communications ability is required.
__________________
When you have a choice, buy American.

Jerry Bransford is online now   Quote Quick Reply
Old 12-07-2013, 04:51 PM   #9
Jeeper

Joe Dirt's Avatar

Join Date: Mar 2007
Location: Murrieta, CA
Posts: 1,075
Thanks Jerry. You're an encyclopedia of knowledge as usual.

Just to be clear, if I get a dual band 1/4 wave antenna for my 2M radio it will work just as good (or close to) as a 2M 1/2 wave antenna, and the dual band antenna will give me the ability to upgrade to a dual band radio later.
__________________
2013 Wrangler 2D, 3.6L, Automatic, 3.73 Gears, Limited slip in the rear, Teraflex 2" lift, 285/75/16 tires, LOD bumper & 8K winch, 2M Ham radio.

People sleep peaceably in their beds at night only because rough men stand ready to do violence on their behalf- George Orwell
Joe Dirt is offline   Quote Quick Reply
Old 12-07-2013, 06:16 PM   #10
Knows a couple things...

WF Supporting Member

Jerry Bransford's Avatar

Join Date: Nov 2005
Location: Escondido, Calif.
Posts: 31,161
Images: 2
Yep, that dual band 1/4 wave should be fine, that's what I used to use and I was perfectly happy with it. It was, as said above, only because of the KOH event that I changed it out for the bigger 5/8 Hustler.

In fact, that little dual-bander I used to run was a mag-mount and I had it mounted inside the TJ on the rear fender well. Even inside it worked fine.
__________________
When you have a choice, buy American.

Jerry Bransford is online now   Quote Quick Reply
Old 12-07-2013, 08:21 PM   #11
Jeeper

hambubba's Avatar

Join Date: Oct 2010
Location: Louisiana
Posts: 241
Send a message via AIM to hambubba
A quarter wave will do wonders. I used a homemade one (Jerry, the famous co-tanga, haha) on the back of the house when I was "new". Believe it or not, I made a digital contact with the MIR station. Just about peed my pants! I also got them on voice while driving down I10. Only for a few seconds, but that too was a cheapo quarter wave.

Your mileage may vary, but you'll love it!
hambubba is offline   Quote Quick Reply
Old 01-07-2014, 06:00 PM   #12
Jeeper

zombiechief's Avatar

Join Date: Feb 2013
Location: Pensacola, FL
Posts: 161
Images: 3
I'm running a 281 with a 5/8 wave MFJ mounted on the back of my YJ.



This is the first place I mounted it but it kept getting beat up on the trails so I moved it inboard behind my spare tire.


Here's where I have my antennas mounted now.


Looks like this now...


It works great back there. I was worried about my jack and CB antenna affecting it, but I haven't noticed any problems from them.
