Snorkel time!?!?

Sooooooo well this past weekend a few friends and my self went and played around in a dry river bed that has some nice crawl spots and some water to play in {still waiting on Dave to get me the pics} but while we were playing in the water i sucked a bit of water into the air box, luckily no water made it past the filter but the filter was damp. So i was looking at snorkels but i just don't have the money for one being as im saving for a nice lift. So does anyone know anyone or have any personal experience in building your own snorkel? I would love to make one that doesn't look like duck tape and 2x4s.
So something decent with possibly plastic tubing or something along those lines. let me know what you got!!!

firstresponder is offline   Quote
Old 06-16-2011, 12:30 PM   #2
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
i do

89JEEPYJ is offline   Quote
Old 06-16-2011, 12:40 PM   #3
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967





thats my snorkel build
89JEEPYJ is offline   Quote
Sponsored Links
Advertisement

Old 06-16-2011, 12:55 PM   #4
Jeeper

danieldlg_13's Avatar

Join Date: Sep 2009
Location: Houston
Posts: 1,012
Send a message via MSN to danieldlg_13 Send a message via Yahoo to danieldlg_13
Try lifting it first, and then if you still are getting water in the filter... make a snorkle.
danieldlg_13 is offline   Quote
Old 06-16-2011, 12:57 PM
Thread Starter
  #5
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
that is beautiful. I do have a few questions. first one is a parts list if you have one would be great! that looks like exhaust pipe if im not mistaken, but as far as those connectors and all that jaz, id like to mimik and recreate that set up. Next how did you mount the hose to the bottom of your air box? mines just an open hole leading into the box. and last is the hole in the hood. i like that as a mount spot but, with that hole there and the pipe going through it, how do you open and close your hood? or do you have to take the pipe out everytime?
firstresponder is offline   Quote
Old 06-16-2011, 12:59 PM
Thread Starter
  #6
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
Quote:
Originally Posted by danieldlg_13 View Post
Try lifting it first, and then if you still are getting water in the filter... make a snorkle.
The whole thing with doing that is, im slowly saving for the lift because bill and all that crap. but i still like to go out on the weekends and play around. And the air box's hole is at the bottom so even splashing water gets in there, and i like the look too haha
firstresponder is offline   Quote
Old 06-16-2011, 01:03 PM   #7
Founder, ThumbJeeps

WF Supporting Member

Chris Larabell's Avatar

Join Date: Sep 2009
Location: Mid-Michigan/Thumb
Posts: 4,062
don't forget to extend the breather tubes on your axles to... or, they'll fill up w/water.
__________________
-Chris
Founder, ThumbJeeps. Mayville, Michigan
"roads are boring"


1994 Wrangler YJ I6 4.0 H/O Auto 3 spd. 3:55 Gears
Chris Larabell is offline   Quote
Old 06-16-2011, 01:05 PM   #8
Jeeper

crtaylor's Avatar

Join Date: Sep 2009
Location: Beaver Falls,PA
Posts: 1,061
__________________
Built Not Bought!
95 Wrangler 2.5" SUA 1"BL / 5.5 Tube Fenders, 31x10.50 BFG KM2, 2.5l 5spd
stinger , XRC winch 8000
Softopper bowless
UPOL Raptor liner
crtaylor is offline   Quote
Old 06-16-2011, 01:13 PM   #9
Jeeper

osu50sprinter's Avatar

Join Date: May 2010
Location: Vail CO
Posts: 158
it kinda looks like you made the hole in the hood so that every time that you open the hood it take the tube with it....is it just me or did you cut the hole so you can still open the hood??
osu50sprinter is offline   Quote
Old 06-16-2011, 01:25 PM   #10
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
Quote:
Originally Posted by firstresponder View Post
that is beautiful. I do have a few questions. first one is a parts list if you have one would be great! that looks like exhaust pipe if im not mistaken, but as far as those connectors and all that jaz, id like to mimik and recreate that set up. Next how did you mount the hose to the bottom of your air box? mines just an open hole leading into the box. and last is the hole in the hood. i like that as a mount spot but, with that hole there and the pipe going through it, how do you open and close your hood? or do you have to take the pipe out everytime?
it is 3 exhaust tube that is mandrill bent. there is a straight pipe a 70 anda 90 degree. which cost me 55. i got a 3 inch saw thingy, i got some pvc piping. i took the stock intake for the box out and put some pvc in there which is a perfect fit. Then i took some flexable tubeing and ran it to the pipe. the hole in the hood is down a bit so they hood opens and closes perfectly. i used a Ubolt and a shackle to hold the pipe in place under the hood, and some exhaust hanger welded to my hinge to hold the top. its very strong, i smash it up against rocks, trees whatever and it holds strong. If u have an automatic transmission u have to do some custom work if u plan to go in some deep water, or if u have a manual just run the breather higher, u need to get the diff breathers, T-case breather, gas breather all at a high spot
89JEEPYJ is offline   Quote
Old 06-16-2011, 01:27 PM   #11
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
i had a write up on my build but i cant seem to find it since it was soo long ago.

opens perfectly
89JEEPYJ is offline   Quote
Old 06-16-2011, 01:29 PM
Thread Starter
  #12
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
Quote:
Originally Posted by crtaylor View Post
Nice build. i like how you mounted the line to your airbox. Now i just have to try and make one, i think im going to get started on it tonight. im guessing all i need is some exhaust pipe, clamps, foam, tape, an MAF housing, and felx tube. anything else?

sevenservicesdon't forget to extend the breather tubes on your axles to... or, they'll fill up w/water.
Yup first thing im doing haha
firstresponder is offline   Quote
Old 06-16-2011, 01:34 PM   #13
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
PVC pipe, pvc cement, some silicon. not many places have mandrill bent exhaust soo that might take u a little to find
89JEEPYJ is offline   Quote
Old 06-16-2011, 01:34 PM
Thread Starter
  #14
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
Quote:
Originally Posted by 89JEEPYJ View Post
it is 3 exhaust tube that is mandrill bent. there is a straight pipe a 70 anda 90 degree. which cost me 55. i got a 3 inch saw thingy, i got some pvc piping. i took the stock intake for the box out and put some pvc in there which is a perfect fit. Then i took some flexable tubeing and ran it to the pipe. the hole in the hood is down a bit so they hood opens and closes perfectly. i used a Ubolt and a shackle to hold the pipe in place under the hood, and some exhaust hanger welded to my hinge to hold the top. its very strong, i smash it up against rocks, trees whatever and it holds strong. If u have an automatic transmission u have to do some custom work if u plan to go in some deep water, or if u have a manual just run the breather higher, u need to get the diff breathers, T-case breather, gas breather all at a high spot
]

Nice i like that. i think im goign to start rounding up the parts tonight and go start moving boxes around till i can find that damn welder. And yes it is the manual tranny so im going to get all that done. are all those breathers somthing i buy or is it as simple and just putting more length on the tubing? ive got miles of tubing floating around the garage
firstresponder is offline   Quote
Old 06-16-2011, 01:34 PM   #15
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
once u get all the stuff needed, it takes like 2 hours, dont make any final welds until u have it bolted down. its always nice to have a filter on it, but for the most part its just putting longer hoses up to a high point of ur truck
89JEEPYJ is offline   Quote
Old 06-16-2011, 01:34 PM   #16
Jeeper

crtaylor's Avatar

Join Date: Sep 2009
Location: Beaver Falls,PA
Posts: 1,061
you can order just the top from ARB ,I have the part number somewhere
its about a $100
thats why I just made my own.
__________________
Built Not Bought!
95 Wrangler 2.5" SUA 1"BL / 5.5 Tube Fenders, 31x10.50 BFG KM2, 2.5l 5spd
stinger , XRC winch 8000
Softopper bowless
UPOL Raptor liner
crtaylor is offline   Quote
Old 06-16-2011, 01:36 PM   #17
Jeeper

crtaylor's Avatar

Join Date: Sep 2009
Location: Beaver Falls,PA
Posts: 1,061
Summit racing has the mandrel pipe pieces
__________________
Built Not Bought!
95 Wrangler 2.5" SUA 1"BL / 5.5 Tube Fenders, 31x10.50 BFG KM2, 2.5l 5spd
stinger , XRC winch 8000
Softopper bowless
UPOL Raptor liner
crtaylor is offline   Quote
Old 06-16-2011, 01:36 PM
Thread Starter
  #18
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
i know a shop here in austin that makes the pipe no problem. what did you use for a pipe cap uptop or is yours just open pipe?
firstresponder is offline   Quote
Old 06-16-2011, 01:38 PM
Thread Starter
  #19
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
yeah i liked the foam style, id probably make one out of foam like that and end put covering it kittyhair, then using a differ fiber reson then a bit of bondo and wala coat of paint and it should look good, wont stand up to the rocks like plastic or metal one but atleast ill have one haha
firstresponder is offline   Quote
Old 06-16-2011, 01:47 PM   #20
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
well for a while i left it open and put a cup on it when it rains, But i have the safari cap. ran me about 74
89JEEPYJ is offline   Quote
Old 06-16-2011, 01:50 PM   #21
Jeeper

crtaylor's Avatar

Join Date: Sep 2009
Location: Beaver Falls,PA
Posts: 1,061
I was going to uae the foam one and cover it with glass but all out of the resin at this time .so I just busted out the welder.
__________________
Built Not Bought!
95 Wrangler 2.5" SUA 1"BL / 5.5 Tube Fenders, 31x10.50 BFG KM2, 2.5l 5spd
stinger , XRC winch 8000
Softopper bowless
UPOL Raptor liner
crtaylor is offline   Quote
Old 06-16-2011, 01:53 PM
Thread Starter
  #22
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
i wonder if i made a cap with a removable filter inside, along with the filter in the box, think id be to much and work harder to pull air? and or put a open/close valve on the pipe under the hood so when it rains i can cap off the top and open the valve so it breaths under the hood again. hmmmm the possibilitys lol
firstresponder is offline   Quote
Old 06-16-2011, 01:55 PM
Thread Starter
  #23
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
Well body work is my side hobby so a can of fiber and filler isnt a rare sight at my house.
firstresponder is offline   Quote
Old 06-16-2011, 09:32 PM   #24
Jeeper

89JEEPYJ's Avatar

Join Date: Oct 2010
Posts: 967
lol there isnt much body work, drilling 3 holes lol. ur over thinking it with all those valves or whatever, there is holes in the buttom of ur airbox that should let any water out. i would say that for the most part the top piece is to keep animals out
89JEEPYJ is offline   Quote
Old 06-16-2011, 11:14 PM
Thread Starter
  #25
Jeeper

firstresponder's Avatar

Join Date: May 2011
Location: Austin, TX
Posts: 403
well as far as body work is going i was just talken bout fiber glassen a nice top. and mine must be clogged because i had to use a shirt to mop up all the water in my airbox last time we went out. it took alot in but luckly the filter didnt let anyby

firstresponder is offline   Quote
